1658623-5
| Manufacturer | |
| Description | Conn IDC Connector RCP 24 POS 2.54mm IDT RA Cable Mount Tube Ribbon Cable Connectors (AMP-LATCH) CONN IDC SOCKET 24POS GOLD Headers & Wire Housings .1CL IDC REC 2X12P MIL 30AU Conn IDC Connector RCP 24 POS 2.54mm IDT RA Cable Mount Tube Product Highlights:PreloadedConnector Type = NOVOHousing Gender = Receptacle24 PositionsReceptacleSearch Keywords:input/output, paddleboard, paddle board 24 Position 2.54 mm Pitch Wire to Board Receptacle Assembly TE Connectivity AMP-LATCH Novo 系列 2行 24路 2.54mm节距 母 IDC 连接器 , 电缆安装 24 NOVO MIL 30DP, LEAD FREE |
| Category |
Business
| Tradename | AMP-LATCH | Product Category | Headers & Wire Housings |
| Standard Package | Rail / Tube | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Leadfree Defin | Not relevant for lead free process | UL File Number | E28476 |
| CSA File Number | LR 7189 | Standard Number | CSA, UL |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage Rating | 250 V 交流 | Voltage - Supply | 250 |
| Resistance - Input | 5000 | Connector Impedance | 刺破式压接 (IDC) |
| Current Rating (Max) | 1A | Connector - Voltage Input | 音叉 |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Width | 6.1 mm [ .2402 in ] | Height | 15.16 mm [ .5968 in ] |
| Length | 35.05 mm [ 1.3799 in ] | Base Type | 不带 |
| Packaging | Bulk | Wire Type | Ribbon Cable |
| Body Color | 黑色 | Cable Exit | Without |
| Cable Type | Ribbon Cable | Wire Gauge | 26-28 AWG |
| Orientation | 直 | Row Spacing | 0.100" (2.54mm) |
| Termination | IDT | Contact Form | Female Socket |
| Contact Type | Female Socket | Lead Spacing | 0.100" (2.54mm) |
| Polarization | Military | 2nd Connector | Without |
| Housing Color | Black | Mounting Type | No |
| Cable End Type | Without | Connector Type | NOVO |
| Contact Finish | Gold Over Palladium Nickel Over Nickel|Gold Over Nickel | Flange Feature | 否 |
| Mounting Style | Cable | Number of Rows | 2 |
| Actuation Force | 不带 | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Housing Material | Thermoplastic |
| Mounting Feature | Without | Package Quantity | 60 |
| Panel Mount Type | 通孔 - 焊接 | Size / Dimension | .08 – .15 mm², 158 – 296 CMA, 28 – 26 美国线规 |
| Termination Rows | IDC | Cable Termination | IDC |
| Termination Style | IDC | 1st Connector Type | 插针接头 |
| 1st Contact Gender | Socket (Female) | Mating Orientation | With |
| Number of Contacts | 24 | Insulation Material | .787 – .94 mm [ .031 – .037 in ] |
| Number of Positions | 24 | Contact Length - Post | 信号（数据） |
| Mounting Hole Diameter | 带有 | Center Contact Material | 2.54 x 2.54 [.100 x .100] |
| Contact Finish - Mating | 锡 | Contact Finish Thickness | 30µin (0.76µm) |
Product Info
| Note | Receptacle can be used in applications requiring non-polarization, as well as m | Type | IDC Connector |
| Gender | RCP | Series | AMP-LATCH NOVO |
| Features | Feed Through | Polarity | 带有 |
| Main Purpose | Feed Through | Product Type | Receptacles / Sockets - Housings |
| Connection Type | Ribbon Cable | With Modem Control | Yes |
| DigiKey Programmable | 不带 | Output Configuration | Free Hanging (In-Line) |
| Application Specifics | Wire-to-Board | ||
Environmental
| Operating Temperature | +105°C | ||
