1658622-4
| Manufacturer | |
| Description | Conn IDC Connector RCP 20 POS 2.54mm IDT RA Cable Mount Ribbon Cable Connectors (AMP-LATCH) CONN IDC SKT 20POS W/POL GOLD AMP-Latch receptacle,0.08-0.15mm²,20way Headers & Wire Housings NOVO RECEPTACLE 20P Conn IDC Connector RCP 20 POS 2.54mm IDT RA Cable Mount Product Highlights:Connector Type = NOVONumber of Positions = 20ReceptacleMating Polarization Method = Center & MilitaryWith Mating PolarizationSearch Keywords:input/output, paddleboard, paddle board CONNECTOR, RCPT, 20POS, 2ROW, 2.54MM, IDC Connector,Receptacle;Novo;20;Gold(30);Tin-Lead;0.100in.x0.100in. TE Connectivity AMP-LATCH Novo 系列 2行 20路 2.54mm节距 直角 母 IDC 连接器 , 电缆安装 20 NOVO MIL/CTR 30DP,LEAD FREE |
| Category |
Business
| Tradename | AMP-LATCH | Product Category | Headers & Wire Housings |
| Standard Package | Rail / Tube | Factory Pack Quantity | 900 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85444920 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Range deg/s | :TE - AMP-LATCH Novo Series | Current Rating (Max) | 1A |
| Voltage - Supply (Min) | 250VAC | ||
Mechanical
| Color | Black | Depth | 7.49mm |
| Pitch | 2.54 mm | Width | 15.97mm |
| Height | 15.97 mm | Length | 22.86mm |
| Weight | 0.002 | Packaging | Bulk |
| Wire Type | Ribbon Cable | Cable Exit | Without |
| Wire Gauge | 26-28 AWG | Row Spacing | 0.100" (2.54mm) |
| Termination | IDT | Contact Type | Female Socket |
| Polarization | Center & Military | 2nd Connector | Without |
| Housing Color | Black | Mounting Type | No |
| Cable End Type | Without | Connector Type | NOVO |
| Contact Finish | Gold Over Palladium Nickel Over Nickel|Gold Over Nickel | Mounting Style | Cable |
| Number of Rows | 2 | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 22.86 mm |
| Mounting Feature | Without | Size / Dimension | 22.86 x 15.97 x 7.49mm |
| Cable Termination | IDC | Termination Style | IDC |
| 1st Contact Gender | Socket (Female) | Mating Orientation | With |
| Number of Contacts | 20 | Contact Termination | :IDC / IDT |
| Number of Positions | 20 | Center Contact Material | 2.54 x 2.54 [.100 x .100] |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Type | IDC Connector | Gender | RCP |
| Series | AMP-LATCH NOVO | Features | Feed Through, Polarizing Key |
| Product Type | Receptacles / Sockets - Housings | Connection Type | Ribbon Cable |
| With Modem Control | Yes | Application Specifics | Wire-to-Board |
Environmental
| Operating Temperature | +105°C | ||
Documents & Media
Similar Parts
