1658608-2
| Manufacturer | |
| Description | Conn D-Subminiature PIN 25 POS 2.76mm IDT RA Cable Mount 25 Terminal 1 Port D-Sub Standard Connectors DSUB B25P IDC RIBBON Standard Cable Connectors CONN D-SUB PLUG 25POS GOLD AMPLIMITE HDF-20 d-sub IDC plug,25 pin Conn D-Subminiature PIN 25 POS 2.76mm IDT RA Cable Mount 25 Terminal 1 Port Product Highlights:ConnectorProduct Series = HDF-20 (Ribbon Cable)Number of Positions = 25PlugWith ContactsSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub PLUG, DSUB, 25WAY Conn;D-Ribbon;CablePlug;25Pos;STR;HDF-20Series;IDC;28-26AWG;FrontMetalShell TE Connectivity AMPLIMITE HDF-20 系列 2.76mm 节距 25 路 IDC D-Sub 带状电缆连接器, 插头, 钢外壳 25 POS HDF PLUG, MS, LEAD FREE |
| Category |
Business
| Product Category | D-Sub Standard Connectors | Standard Package | Rail / Tube |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
| Rad Hardened | No | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Range deg/s | :TE CONNECTIVITY - Amplimite HDF-20 Series | Voltage Rating | 30 V ac |
| Current Rating (Max) | 1.25A | Voltage - Supply (Min) | 30VAC |
Mechanical
| Color | Black | Depth | 12.59mm |
| Pitch | 2.76 mm | Width | 18.56mm |
| Height | 18.56 mm | Length | 53.08mm |
| Weight | 0.004 | Packaging | Tube |
| Cable Type | Ribbon Cable | Shell Size | 3 |
| Termination | IDT | Contact Size | 20 |
| Contact Type | Signal | 2nd Connector | With |
| Cable Opening | 747275-2 | Mounting Type | Cable Mount |
| Shell Plating | Tin | Connector Type | Insulation Displacement Crimp (IDC) |
| Contact Finish | Gold | Flange Feature | Housing/Shell (4-40) |
| Mounting Style | Wire | Number of Rows | 2 |
| Shell Material | Steel | Connector Style | D-Sub |
| Insert Material | Brass | Locking Feature | Threaded Insert, 4-40 UNC |
| Material - Body | :Metal | Material Finish | None |
| Profile (W x H) | Low | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 53.08 mm |
| Size / Dimension | 53.08 x 18.56 x 12.59mm | Grounding Indents | With |
| Termination Style | Crimp | Number of Contacts | 25 |
| Contact Termination | :Crimp | Insulation Diameter | 0.81 â 0.97 [0.032 â 0.038] |
| Number of Positions | 25 | Shell Size - Insert | Front Metal Shell |
| Shell Material, Finish | Steel, Tin Plated | Thread/Screw/Hole Size | Standard |
| Contact Finish Thickness | Flash | Exterior Housing Material | Thermoplastic |
| Wire Gauge or Range - AWG | 0.08 - 0.15 [28-26] | Shell Size, Connector Layout | 3 (DB, B) |
Product Info
| Note | All plug assemblies are supplied with housing and cover preassembled | Type | D-Subminiature |
| Grade | Standard | Gender | PIN |
| Series | HDF-20 | Features | Feed Through, Grounding Indents |
| Pair Number | 747275-2 | Product Type | Connector |
| Number of Ports | 1 Port | ||
Environmental
| Operating Temperature | -55°C ~ 105°C | ||
