1648205-1
| Manufacturer | |
| Description | Conn Housing PIN 4/21 POS Crimp ST Cable Mount High Power Drawer - Elcon CONN PIN LOWER DRAWER 16/20/12 Elcon,lower drawer,hsng,plug,29way Heavy Duty Power Connectors PIN HOUSING CONN SIZE 12 16 20 1648205-1 Conn Housing PIN 4/21 POS Crimp ST Cable Mount Product Highlights:HousingContact Size = 12, 16, 20Drawer Style = LowerPinSize 12 + Size 20 + Size 16 Contact Configuration Elcon,lowerdrawer,hsng,plug,29way |
| Category |
Business
| Product Category | Heavy Duty Power Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 45 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Wave solder capable to 260°C / Wave solder capable to 240°C / Wave solder capabl |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Current Rating (Max) | 35 | ||
Mechanical
| Color | Black | Depth | 22.09mm |
| Length | 82.8mm | Packaging | Bulk |
| Contact Size | 12 / 16 / 20 | Contact Type | Size 12 + Size 20 + Size 16 |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Housing for Male Pins | Contact Finish | Gold |
| Number of Rows | 3 | Connector Style | Plug |
| Connector Usage | Plug | Insertion Force | Male |
| Contact Material | Brass | Housing Material | Thermoplastic - GF |
| Primary Material | Receptacle | Termination Style | Cable |
| Number of Contacts | 4/21 | Number of Positions | 29 (21 + 8 Power) |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PIN | Series | ELCON |
| Features | Mating Guide | Preloaded | No |
| Manufacturer | Elcon | Product Type | Connector |
| Drawer Quantity | Lower | For Use With/Related Products | Power Connector |
