1648204-1
| Manufacturer | |
| Description | Conn Housing PL 4/21 POS Crimp ST Cable Mount High Power Drawer - Elcon CONN PIN LOWER DRAWER 16/20/16 Heavy Duty Power Connectors PIN HOUSING CONN SIZE 16 20 1648204-1 High Current ELCON Drawer Connectors High Current ELCON Drawer Connectors Product Highlights:HousingHousing Type = PlugContact Size = 16, 20Drawer Style = LowerSize 16 + Size 20 + Size 16 Contact Configuration |
| Category |
Business
| Standard Pack | 45 | Product Category | Heavy Duty Power Connectors |
| Standard Package | Bulk | Factory Pack Quantity | 45 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Wave solder capable to 260°C / Wave solder capable to 240°C / Wave solder capabl |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Current Rating (Max) | 35 | ||
Mechanical
| Color | Black | Packaging | Bulk |
| Contact Size | 16 / 20 | Contact Type | Size 16 + Size 20 + Size 16 |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Housing for Male Pins | Number of Rows | 3 |
| Connector Style | Plug | Connector Usage | Plug |
| Housing Material | Thermoplastic - GF | Number of Contacts | 4/21 |
| Number of Positions | 29 (21 + 8 Power) | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Features | Mating Guide |
| Preloaded | No | Manufacturer | Elcon |
| Product Type | Connector | Drawer Quantity | Lower |
