1648163-1
| Manufacturer | |
| Description | Conn Housing PIN 4/24/9 POS Crimp ST Panel Mount High Power Drawer - Elcon CONN PIN MID-DRAWER 8/20/12 PCB Heavy Duty Power Connectors PIN HOUSING CONN SIZE 8 12 20 RECTANGULAR POWER CONNECTOR, PLUG, 37POS |
| Category |
Business
| Product Category | Heavy Duty Power Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 30 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85366910 |
| Leadfree Defin | Wave solder capable to 260°C / Wave solder capable to 240°C / Wave solder capabl | RoHSELV Compliance | RoHS compliant / ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Current Rating (Max) | 75 | ||
Mechanical
| Color | Black | Weight | 0 |
| Packaging | Bulk | Contact Size | 8 / 12 / 20 |
| Contact Type | Size 8 + Size 12 + Size 20 | Housing Color | Black |
| Mounting Type | Fixed | Connector Type | Housing for Male Pins |
| Contact Finish | :- | Connector Style | Plug |
| Connector Usage | Plug | Insertion Force | Male |
| Contact Material | :- | Housing Material | Thermoplastic - GF |
| 1st Contact Gender | :- | Number of Contacts | :37 |
| Contact Termination | :- | Number of Positions | 37 (24 + 13 Power) |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Note | Contacts Not Provided | Gender | :Plug |
| Series | :- | Features | Guide Pin |
| Preloaded | No | Manufacturer | Elcon |
| Product Type | Connector | Drawer Quantity | Middle |
Documents & Media
