1648162-1
| Manufacturer | |
| Description | Conn Housing PIN 4/24/9 POS Crimp ST Panel Mount High Power Drawer - Elcon CONN PIN MID-DRAWR 8/20/12 CRIMP Heavy Duty Power Connectors PIN HOUSING CONN SIZE 8 12 20 Conn Housing PIN 4/24/9 POS Crimp ST Panel Mount Product Highlights:HousingContact Size = 8, 12, 20Drawer Style = MiddlePinSize 8 + Size 12 + Size 20 Contact Configuration 261-0006-01100 |
| Category |
Business
| Product Category | Heavy Duty Power Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 30 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Wave solder capable to 260°C / Wave solder capable to 240°C / Wave solder capabl |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Current Rating (Max) | 75 | ||
Mechanical
| Color | Black | Packaging | Bulk |
| Contact Size | 8 / 12 / 20 | Contact Type | Size 8 + Size 12 + Size 20 |
| Housing Color | Black | Mounting Type | Straight |
| Connector Type | Housing for Male Pins | Mounting Style | Straight |
| Connector Style | Plug | Connector Usage | Plug |
| Insertion Force | Male | Housing Material | Thermoplastic - GF |
| Number of Contacts | 4/24/9 | Number of Positions | 37 (24 + 13 Power) |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PIN | Features | Guide Pin |
| Preloaded | No | Manufacturer | Elcon |
| Product Type | Connector | Drawer Quantity | Middle |
