1586314-1
| Manufacturer | |
| Description | Contact PIN Crimp ST Cable Mount Loose Piece VAL-U-LOK Series Connector System CONN TERM PIN 18-22AWG TIN 4.2 PE series 22-18 awg contact pin Pin & Socket Connectors 4.2MM PIN 22-18AWG BRASS-TIN Conn Contact PIN 1 POS Crimp ST Cable Mount Loose Piece Contact PIN Crimp ST Cable Mount Loose Piece Product Highlights:ContactPinWire Range = 0.20-0.80² [24-18] mm [AWG]Brass MaterialSearch Keywords:wire to wire, wire to board, soft shell, Power Pin & Socket, NIC, Network Interface Cards, PC Cards, Cabled Power, pcb connectors, discrete wire, crimp, Power Economy, Molex Mini-Fit Jr, VAL-U-LOK, 4.2mm, PE, PE Series Connector System, .165 Centerline PE, Valulok, PWRSIGALLP CONTACT, PIN, 24-18 AWG, CRIMP Contact,Pin,VAL-U-LOK,WiretoWire,18-24AWG,600VAC,9A Crimp pin Male 22...18 AWG, 1586314-1, TE Connectivity TE Connectivity VAL-U-LOK 系列 公 压接接线端子, 压接, 镀锡触点 VAL-U-LOK PIN BR TN 24-18 LP |
| Category |
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
Electrical
| Voltage Rating | 600 V | Contact Resistance | 10mΩ |
| Current Rating (Max) | 9 A | ||
Mechanical
| Weight | 0.013 | Plating | Pre-Tin |
| Material | Brass | Packaging | Bulk |
| Wire Gauge | 18-22 AWG | Termination | Crimp |
| Contact Type | Signal | Pin or Socket | Pin |
| Connector Type | Connector Headers and PCB Receptacles | Contact Finish | Pre-Tin |
| Material Finish | :- | Contact Material | Brass |
| Package Quantity | Loose Piece | Termination Style | Crimp |
| 1st Contact Gender | Pin (Male) | Contact Termination | Crimp |
| Insulation Diameter | 1.50 â 2.40 [0.059 â 0.094] | Wire Gauge or Range - AWG | 22-18 |
| Wire Gauge or Range - mm2 | 0.30-0.90² [22-18] | ||
Product Info
| Gender | PIN | Series | PE |
| CAD Drawing | 3D CAD Model | Product Type | Contact |
| For Use With/Related Products | :VAL-U-LOK Series Connector System | ||
Environmental
| Operating Temperature | 105°C | ||
Documents & Media
