Business
| Tradename | AMPMODU | Product Category | Headers & Wire Housings |
| Standard Package | Rail / Tube | Factory Pack Quantity | 44 |
Compliance
| RoHS | Not applicable / RoHS non-compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage - Supply | 267 V | Contact Resistance | 15 mΩ |
| Resistance - Input | 5000 | Connector Impedance | 刺破式压接 (IDC), 压接 |
| Current Rating (Max) | 3 A | Voltage - Protection Rating (VPR) | 600 VAC |
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.6 mm [ .26 in ] | Length | 50.3 mm [ 1.98 in ] |
| Lock Type | 锁闩 | Packaging | Tube |
| Wire Type | Ribbon Cable | Body Color | 黑色 |
| Wire Gauge | 22-26 AWG | Row Spacing | 2.54 mm |
| Termination | IDT | Contact Type | Male Pin |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Plug |
| Contact Finish | Bright Tin-Lead Over Nickel | Mounting Style | Wire |
| Number of Rows | 1 | Insert Material | 磷青铜 |
| Contact Material | Phosphor Bronze | Housing Material | Thermoplastic |
| Package Quantity | 44 | Panel Mount Type | 不带 |
| Cable Termination | IDC | Termination Style | Crimp |
| 1st Contact Gender | Pin (Male) | Number of Contacts | 4 |
| Number of Positions | 4 | Compatible Shell Size | 配合母端 |
| Mounting Hole Diameter | 带有 | Contact Layout, Typical | 同轴 |
| Contact Finish Thickness | 100µin (2.54µm) | Static Discharge Shielding | 带有 |
| Contact Finish - Post (Mating) | 亮光 | ||
Product Info
| Note | 带状电缆带缺口把手 22-28 AWG, 气动终结器的最大绝缘直径为 1.14 [0.045]。 | Type | IDC Connector |
| Gender | RCP | Series | AMPMODU MTE |
| Features | Closed End | Product Type | Headers |
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | - 65 C to + 105 C |
