102387-9

Manufacturer	TE Connectivity Ltd.
Description	Conn Housing RCP 40 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 40POS .100 POL DUAL Housing FH 40way 2row Rec 2.54mm AmpModu Headers & Wire Housings CNTR PLRZD HG 40 DBL Conn Housing RCP 40 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 40Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE CONNECTOR, IDC Housing,Connector;ModIV;Dual;40;250VAC;3A;750VNo Crimp housing Pitch2.54 mm Poles 40 Double row / straight / with polarization AMPMODU MOD IV, 102387-9, TE Connectivity TE Connectivity AMPMODU Mod IV 系列 2 行 2.54mm 节距 40 路直母电缆安装 PCB 壳体 40 MODIV HSG COMP DR .100 POL
Category	Connector SolutionsCrimp & Solder Terminals / SplicesCrimp Terminals

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	1

Compliance

RoHS	Lead free / RoHS Compliant	Standards	ULListed,CSACertified,RoHSCompliant,ELVCompliant
Tariff No	85369010	Approval Agency	CSA,UL

Electrical

Range deg/s	:TE - AMPMODU Mod IV Series	Voltage Rating	250 VAC
Voltage - Breakdown	750V	Current Rating (Max)	3 A
Insulation Resistance	5000Megohms	Voltage - Supply (Min)	250VAC

Mechanical

Color	Black	Depth	15.24mm
Pitch	2.54 mm	Width	7.23mm
Height	7.23 mm	Length	55.37mm
Weight	0.004	Packaging	Bulk
Wire Gauge	22-30 AWG	Row Spacing	0.100" (2.54mm)
Termination	:Crimp	Contact Type	Female Socket
Lead Spacing	:2.54mm	Polarization	Yes
Housing Color	Black	Mounting Type	Straight
Angle of Throw	Straight	Connector Type	Receptacle
Contact Finish	:-	Number of Rows	2
Contact Material	:-	Housing Material	Thermoplastic
Length - Overall	55.37 mm	Primary Material	InterconnectSystem
Connector - Cable	No	Pin Hole Diameter	0.1"
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Number of Contacts	40	Contact Termination	Crimp
Number of Positions	40

Product Info

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Series	Mod IV
Features	Polarizing Key	Manufacturer	AMPMODU/MODIVSeries
Product Type	Receptacles / Sockets - Housings	Matrix (Columns x Rows)	0.100x0.100in.
For Use With/Related Products	Centerline Double-Row Connector

Environmental

Operating Temperature

- 65 C to + 105 C
