1-967584-1
| Manufacturer | |
| Description | Conn Housing RCP 4 POS 2.54mm Crimp ST Cable Mount Loose Piece MQS - Connectors CONN PLUG HSNG 4POS BLACK Conn Housing RCP 4 POS 2.54mm Crimp ST Cable Mount Loose Piece Product Highlights:HousingNumber of Positions = 4Contact Style = MQS4 MQS ContactsHousing Type = PlugSearch Keywords:Wire Termination and Splices, VDA, MPQ, PQ, power, terminal and splices, dead end plug, MQS ST-GEH EDS4P,SW |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Voltage Rating | 12, 24 | Voltage - Supply | 24 |
| Connector Impedance | 否 | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Width | 40.1 mm [ 1.579 in ] | Height | 12.8 mm [ 0.504 in ] |
| Length | 19.5 mm [ .768 in ] | Packaging | Bulk |
| Cable Exit | 否 | Contact Type | Male Pin |
| Mounting Type | Straight | Connector Type | Plug |
| Number of Rows | 2 | Terminal Style | Yes |
| Locking Feature | On the terminal | Mounting Feature | Yes |
| Primary Material | PBT GF | Connector - Cable | No |
| Pitch - Connector | .217, .234, .299 | Number of Contacts | 4 |
| Number of Positions | 4 | Pin Size - Above Flange | .63 mm [ .025 in ] |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Features | Sealed |
| Polarity | 是 | Sealable | 是 |
| Serviceable | Yes | Other Specifications | GEN |
| Application Specifics | Signal | ||
Environmental
| Operating Temperature | -40 – 120 °C [ -40 – 248 °F ] | ||
