1-822473-3
| Manufacturer | |
| Description | Conn PLCC Socket SKT 32 POS 2.54mm Solder ST Thru-Hole Tube PLCC Sockets CONN SOCKET PLCC 32POS 2.54 32way through hole PLCC skt,0.1in grid IC & Component Sockets PLCC 32P T/H Conn PLCC Socket SKT 32 POS 2.54mm Solder ST Thru-Hole Tube Product Highlights:Socket Type = PLCC - StandardNumber of Positions = 322.54 mm CenterlineNormal Insertion ForceThru HoleSearch Keywords:IC sockets, NIC, Network Interface Cards, PC Cards, Plastic Leaded Chip Carrier, JEDEC MS-018, JEDEC MS-016-AE, EIA 481, JEDEC MO-047AA-AH, JEDEC MO-052-AE, JEDEC MO-061, JEDEC MS-016, SOCKET IC, PLCC, 32WAY Socket,PLCC;32Positions;0.100in |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | PLCC Sockets | Product Category | IC & Component Sockets |
| Standard Package | Rail / Tube | Factory Pack Quantity | 1595 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Rad Hardened | No | Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| Approval Agency | :UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 V ac | Contact Resistance | 20 mohm |
| Current Rating (Max) | 1A | Insulation Resistance | 1000 Mohm |
| Connector - Voltage Input | :Through Hole Mounting | ||
Mechanical
| Depth | 20.54 mm | Pitch | 2.54 mm |
| Width | :20.54mm | Height | 8.1mm |
| Length | :20.54mm | Weight | 0.002 |
| Packaging | Tube | Frame Type | Closed |
| Termination | Solder | Lead Spacing | :2.54mm |
| Pitch - Post | :2.54mm | Polarization | Without |
| Mounting Type | Through Hole | Angle of Throw | Straight |
| Connector Type | :PLCC | Contact Finish | Tin over Nickel |
| Mounting Style | Through Hole | Insertion Force | Normal |
| Material - Body | Thermoplastic | Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic | Length - Overall | 2.54 [0.100] |
| Package Quantity | Tube | Primary Material | PLCC |
| Pin Hole Diameter | 0.1In. | Height Above Board | 8.45 [0.333] |
| Number of Contacts | 32 | Contact Termination | :Through Hole Vertical |
| Insulation Material | Thermoplastic | Number of Positions | 32 |
| Contact Finish Thickness | 80µin (2.03µm) | 1st Connector Mounting Type | :PC Board |
| Number of Positions or Pins (Grid) | 32 (2 x 7, 2 x 9) | ||
Product Info
| Type | PLCC Socket | Gender | SKT |
| Series | :- | Features | Closed Frame |
| CAD Drawing | 3D CAD Model | Socket Type | PLCC - Standard |
| Manufacturer | 822473Series | Configuration | Square |
Environmental
| Operating Temperature | +170°C | ||
