1-794617-8
| Manufacturer | |
| Description | Conn Housing RCP 18 POS 3mm ST 3mm Centerline, 250V, 5 A max. CONN RCPT 3MM 18POS DL MATE-N-L Housing FH 18 way 2 row Rec M Mate-n-Lok Pin & Socket Connectors RECPT DUAL ROW 18P Conn Housing RCP 18 POS 3mm ST Product Highlights:HousingHousing Type = ReceptacleNumber of Positions = 18Number of Rows = Dual3.00 mm CenterlineSearch Keywords:wire to board, wire to wire, high density, Power Pin & Socket, Soft Shell, Lighting Interconnection, wire to panel, power, pcb connectors, discrete wire, crimp,
low profile, Micro MATE-N-LOK connector, MATE-N-LOK connector, Low Profile Soft Shell connector, Lighting, LED Lighting, Lighting Applications, Soft Shell connector, Low profile Micro MATE-N-LOK connector PIN & SOCKET CONNECTOR HOUSING Connector,SoftShell;Nylon;Receptacle;Black;18;Dual;0.118in.;UL94V-0 Crimp housing Pitch3 mm Poles 2 x 18 MATE-N-LOK Micro, 1-794617-8, TE Connectivity TE Connectivity Micro MATE-N-LOK 系列 2 行 3mm 节距 18 路 直 母 电缆安装 连接器外壳 18POS,MICRO MNL,RCPT HSG |
| Category |
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 250 V | Current Rating (Max) | 5 A |
| Voltage - Supply (Min) | 250VAC | ||
Mechanical
| Color | Black | Depth | 11.7mm |
| Pitch | 3 mm | Width | 8.26mm |
| Height | 11.7 mm | Length | 28mm |
| Weight | 0.00159 | Packaging | Bulk |
| Wire Gauge | 20 AWG | Row Spacing | 0.118" (3.00mm) |
| Contact Type | Female Socket | Housing Color | Black |
| Mounting Type | Straight | Connector Type | Receptacle |
| Fastening Type | Latch Lock | Mounting Style | Wire |
| Number of Rows | 2 | Package / Case | Receptacle |
| Contact Material | Phosphor Bronze | Housing Material | Nylon |
| Length - Overall | 3.00 [0.118] | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Color - Connectors | :Black |
| Number of Contacts | 18 | Contact Termination | Crimp |
| Number of Positions | 18 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | Mate-N-Lok |
| Product Type | Housing | For Use With/Related Products | PCB Connector |
Environmental
| Operating Temperature | -40C to 105C | ||
