1-1103641-1
| Manufacturer | |
| Description | Connector Accessories Female Insert 25 POS Screw Terminal Hard Silver Loose Piece HTS Connectors and Accessories CONN FEMALE INSERT HE.24 SERIES HE 24 way screw terminal female insert Heavy Duty Power Connectors SKT INSERT 24+PE HE.24 SIZE 8 Connector Accessories Female Insert 25 POS Screw Terminal Hard Silver Loose Piece Product Highlights:HE.24 SeriesInsertProduct Size = 8Contact Type = Screw TerminalInsert Style = SocketSearch Keywords:cabled power, DIN VDE 0110, DIN VDE 0627, DIN IEC707/VDE 0304, self extinguishing, non-flammable, European Metal Shell connector, rectangular industrial, input/output, box to box, Heavy Duty Connectors, Motorman, Motorman Hybrid, ELFA®, frequency converter, SurTec 650 INSERT, FEMALE, SCREW, 24WAY HE24WAYSCREWTERMINALFEMAL Connector: HTS; female; HTS HE; PIN:24; 24+PE; size 8; 16A; 400V TE Connectivity HE 系列 大负荷电源连接器套件 HE.24.BU.S.1-24 |
| Category |
Business
| Product Category | Heavy Duty Power Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 5 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | CSA, DIN VDE 0110, DIN VDE 0627, SEV, UL |
| Tariff No | 85369010 | Approval Agency | :CSA, SEV, UL |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Voltage Rating | 400V | Current Rating (Max) | 16A |
Mechanical
| Size | 8 | Color | Gray |
| Depth | 33 mm | Height | 34 mm |
| Weight | 0.22 | Material | thermoplastic |
| Boreholes | 104mm | Packaging | Bulk |
| Termination | :Screw | Mounting Type | screw terminal |
| Connector Type | Insert | Contact Finish | Silver |
| Mounting Style | for cable | Number of Rows | :2 |
| Package / Case | size 8 | Insertion Force | Female |
| Contact Material | :Copper | Housing Material | Polycarbonate (PC), Glass Filled |
| Length - Overall | 110 mm | Package Quantity | 5 |
| Primary Material | IndustrialRectangular | Size / Dimension | 8 |
| Termination Style | Screw | 1st Contact Gender | :Socket |
| Diameter - Outside | 110mm | Number of Contacts | 24 |
| Contact Termination | :Screw | Cross Section Shape | 0.5...2.5mm2 |
| Number of Positions | 24+Ground | Shell Size - Insert | :8 |
| Diameter - Small Outside | 27mm | Contact Material - Plating | silver plated |
| 1st Connector Mounting Type | :Panel | 1st Connector Mounting Feature | 24+PE |
Product Info
| Spg | 5 | Type | Insert |
| Gender | Female | Series | HE.24 |
| Manufacturer | HTS | Product Type | Inserts |
| Adapter Series | HTS HE | Number of Units | 1 |
| RF Family/Standard | 1103641 | Other Specifications | 33mm |
