1-102394-1
| Manufacturer | |
| Description | Conn Housing RCP 26 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts 26 AMP MODU MT HSG DR .100CL Headers & Wire Housings 26P MT HSG DR .100CL 26 AMP MODU MT HSG DR .100CL Search Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE |
| Category |
Business
| Tradename | AMPMODU | Standard Pack | 90 |
| Product Category | Headers & Wire Housings | Standard Package | Trays |
Compliance
| RoHS | Lead free / RoHS Compliant | Standard Number | CSA LR7189, UL E28476 |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage - Supply | 250 VAC | Contact Resistance | 15 mΩ |
| Resistance - Input | 5000 | Connector Impedance | 刺破式压接 (IDC) |
| Current Rating (Max) | 3 A | Connector - Voltage Input | IDC |
| Voltage - Protection Rating (VPR) | 600 V | ||
Mechanical
| Color | Black | Pitch | 2.54 mm |
| Height | 6.1 mm [ .24 in ] | Length | 30.02 mm [ 1.18 in ] |
| Lock Type | 不带 | Packaging | Bulk |
| Body Color | 黑色 | Wire Gauge | 20-30 AWG |
| Row Spacing | 0.100" (2.54mm) | Contact Type | Female Socket |
| Lead Spacing | 0.100" (2.54mm) | Mounting Type | Straight |
| Connector Type | Receptacle | Mounting Style | Wire |
| Number of Rows | 2 | Housing Material | Thermoplastic |
| Package Quantity | 90 | Termination Style | IDC |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 26 |
| Contact Termination | IDC | Number of Positions | 26 |
| Compatible Shell Size | 连接器 | Mounting Hole Diameter | 不带 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | AMPMODU MT |
| Product Type | Receptacles / Sockets - Housings | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | - 65 C to + 105 C |
