1-102387-3

Manufacturer	TE Connectivity Ltd.
Description	Conn Housing RCP 44 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 44POS .100 POL DUAL AmpModu IV receptacle Housing 22+22 way Headers & Wire Housings 44P HOUSING Conn Housing RCP 44 POS 2.54mm Crimp ST Cable Mount Product Highlights:HousingNot PreloadedNumber of Positions = 44Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE TE Connectivity AMPMODU Mod IV 系列 2 行 2.54mm 节距 44 路直母电缆安装 PCB 连接器外壳 44 MOD IV HSG COMP DR .100 POL
Category	Connector SolutionsRectangular ConnectorsHigh-Reliability Rectangular Connectors

对参数有疑问？问 AI 助手

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	1

RoHS	Lead free / RoHS Compliant	Standard Number	CSA LR7189, UL E28476
Material Flammability Rating	UL 94V-0

Voltage Rating	250 VAC	Voltage - Supply	250 VAC
Contact Resistance	12 mΩ	Resistance - Input	5000
Connector Impedance	压接	Current Rating (Max)	3 A
Voltage - Protection Rating (VPR)	750 V

Color	Black	Depth	15.24mm
Pitch	2.54 mm	Width	7.24mm
Height	7.23 mm [ .285 in ]	Length	60.45mm
Lock Type	不带	Packaging	Bulk
Body Color	黑色	Wire Gauge	22-30 AWG
Orientation	直	Row Spacing	0.100" (2.54mm)
Contact Type	Female Socket	Mounting Type	Straight
Connector Type	Receptacle	Number of Rows	2
Insert Material	铍铜	Housing Material	Glass Fibre Reinforced Thermoplastic
Package Quantity	1	Termination Style	Crimp
1st Contact Gender	Socket (Female)	Number of Contacts	44
Contact Termination	Crimp	Number of Positions	44
Compatible Shell Size	公端	Mounting Hole Diameter	带有
Termination Post Length	Crimp	Static Discharge Shielding	不带

Note	Contacts Not Provided	Type	Housing
Gender	RCP	Series	MOD IV
Features	Polarizing Key	Product Type	Connectors
Other Specifications	否	Application Specifics	Board-to-Board
For Use With/Related Products	MOD 1/2 Wire to Board Standard Pressure Contact
