MTA106EPC
| Manufacturer | |
| Description | Toggle Switches SPDT ON-OFF-ON PC SWITCH TOGGLE SPDT 6A 125V Switch Toggle ON OFF ON SPDT Long Bat Toggle PC Pins 6A 250VAC 28VDC PC Mount with Threads Switch Toggle ON OFF ON SPDT Long Bat Toggle PC Pins 6A 250VAC 28VDC PC Mount with Threads Product Highlights:MTA SeriesSingle Pole - Double Throw Configuration (Pole-Throw)Current Rating = 6 Amps.Mount Style = Through-HoleTermination Type = Printed Circuit, Vertical Switch,Toggle,SinglePole,6A,thruhole, MTA106EPC=(MSTA) SW TOG P/C TE |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 101 Days | Subcategory | Switch Toggle |
| Part # Aliases | 1-1437558-3 | Product Category | Toggle Switches |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Circuit | SPDT | Operation | OnOffOn |
| Current - UL | 3 | Voltage Rating | 125V |
| Frequency - Max | 单极 - 双掷 | Switch Function | On-Off-On |
| Contact Resistance | 10 | Resistance - Input | 1000 |
| Voltage - Breakdown | 1500 | Current Rating (Max) | 6A (AC), 4A (DC) |
| Switch Function/Rating | 开关开 | Connector - Voltage Input | 银打底镀金, 银打底镀金 |
Mechanical
| Color | 绿色 | Length | 10.49 mm [ .413 in ] |
| Packaging | Bulk | Termination | PCBpins |
| Contact Form | SPDT | Actuator Type | Standard Round |
| Mounting Type | Panel Mount | Bushing Thread | 1/4-40 |
| Contact Finish | Gold Flash over Silver | Mounting Style | Through Hole |
| Actuator Length | 10.49mm | Insert Material | 铜合金 |
| Actuator Material | Copper Alloy, Chrome Plated | Termination Style | PC Pin |
| Bushing, Grommet Type | 1/4-40 | Mounting Hole Diameter | 0.072In. |
| Panel Cutout Dimensions | Circular - 6.40mm Dia | Contact Material - Mating | 铬 |
Product Info
| Note | 订购时可选择美国安全检测实验室公司 - 咨询工厂。 | Type | Toggle |
| Style | 长棒 | Series | MTA |
| Features | Epoxy Sealed Terminals | Switch Type | 切换 |
| Illumination | Non-Illuminated | Product Type | 开关 |
| Electrical Life | 60,000 Cycles | Reset Operation | 垂直 |
| Industry Aliases | 1-1437558-3, MTA106EPC | ||
Environmental
| Seal Rating | Sealed | Ingress Protection | 否 |
| Operating Temperature | -20°C ~ 80°C | ||
