MTA106E
| Manufacturer | |
| Description | Toggle Switches SPDT ON-OFF-ON BAT LUG TOGGLE SWITCH SWITCH TOGGLE SPDT 6A 125V Toggle switch SPDT On-Off-On MTA series Switch,Toggle,PanelMnt,6A,125VAC,SPDT,On Switch Toggle ON OFF ON SPDT Long Bat Toggle Wire Lug 6A 250VAC 28VDC Panel Mount with Threads Switch Toggle ON OFF ON SPDT Long Bat Toggle Wire Lug 6A 250VAC 28VDC Panel Mount with Threads Product Highlights:MTA SeriesSingle Pole - Double Throw Configuration (Pole-Throw)Current Rating = 6 Amps.Mount Style = PanelTermination Type = Vertical, Wire Lugs Switch,Toggle;PanelMnt;6A;125VAC;SPDT;On-Off-On;Solder/QC TE Connectivity 单刀双掷 切换开关, 开 - 关 - 开, 4 A @28 V 直流 MTA106E=(MSTA) SWITCH TOGGLE S |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 101 Days | Subcategory | Switch Toggle |
| Part # Aliases | 1-1437558-2 | Product Category | Toggle Switches |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | ULListed |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Circuit | SPDT | Operation | OnOffOn |
| Current - UL | 3 | Voltage Rating | 125V |
| Frequency - Max | 单极 - 双掷 | Number of Poles | 1 |
| Switch Function | On-Off-On | Contact Resistance | 20mΩ |
| Resistance - Input | 1000 | Voltage - Rated AC | 125V |
| Dielectric Strength | 1000VAC | Voltage - Breakdown | 1500 |
| Current Rating (Max) | 6A (AC), 4A (DC) | Insulation Resistance | 1000Megohms(Min.)@500VDC(Min.)for1Minute |
| Switch Function/Rating | On-Off-On | Contact Rating (Current) | 6 A |
| Connector - Voltage Input | 银打底镀金, 银打底镀金 | ||
Mechanical
| Color | 绿色 | Length | 10.49 mm [ .413 in ] |
| Packaging | Bulk | Light Color | Non-Illuminated |
| Termination | SolderLugs | Contact Form | SPDT |
| Shell Finish | Epoxy | Actuator Type | Standard Round |
| Cable Opening | Circular - 6.40mm Dia | Mounting Type | Panel Mount |
| Terminal Type | Through Hole | Bushing Thread | 1/4-40 |
| Connector Type | 通孔 | Contact Finish | Gold Flash over Silver |
| Mounting Style | Through Hole | Actuator Length | 10.49mm |
| Insert Material | 铜合金 | Material - Body | Thermoset(94V-0) |
| Contact Material | Silver Clad Copper Alloy | Actuator Material | Copper Alloy, Chrome Plated |
| Termination Style | Solder Lug | Panel Cutout Shape | 0.256in |
| Number of Positions | 3 | Bushing, Grommet Type | 1/4-40 |
| Mounting Hole Diameter | 0.25In. | Contact Layout, Typical | SPDT |
| Panel Cutout Dimensions | Circular - 6.40mm Dia | Contact Material - Mating | 铬 |
Product Info
| Note | 订购时可选择美国安全检测实验室公司 - 咨询工厂。 | Type | Toggle |
| Style | 长棒 | Series | MTA |
| Features | Epoxy Sealed Terminals | Function | Y |
| Switch Type | 切换 | Circuit Type | SPDT |
| Illumination | Non-Illuminated | Product Type | 开关 |
| Electrical Life | 60,000 Cycles | Reset Operation | 垂直 |
| Industry Aliases | 1-1437558-2, MTA106E | Output Configuration | Panel Mount |
| Application Specifics | Industrialmachineryandequipment,militaryandcommercialaviation,constructionequipment,testinstruments,agriculturalmachinery,processcontrol,medicalinstrumentation | ||
Environmental
| Seal Rating | Sealed | Mechanical Life | 50000Cycles |
| Ingress Protection | 否 | Operating Temperature | -20°C ~ 80°C |
| Operating Temperature - Junction | +80°C | ||
