MTW30-51212
| Manufacturer | |
| Description | AC/DC Power Supply Triple-OUT 5V/12V/-12V 3A/1.2A/0.3A 30W 9-Pin AC/DC CONVERT 5V +/-12V 30W Linear and Switching Power Supplies 30W 5V 12V 3A -12V/0.3A |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Approval Agency | CSA, EN, UL |
Electrical
| Frequency | 47 to 440 Hz | Efficiency | 76(Typ) % |
| Power - Max | 30 W | Output Power | 30 W |
| Power (Watts) | 30W | Voltage Rating | 85 to 265 V |
| Current - Output | 3|1.2|0.3 A | Number of Outputs | 3 |
| Power Supply Type | Switching (Open Frame) | Voltage - Output 3 | - 12 V |
| Power (Watts) - Max | 30W | Voltage - Isolation | 3000VAC |
| Current Rating (Max) | 0.8(Typ) A | Voltage - Input (Min) | 5V, ±12V |
| Current - Output / Channel | 1.2 A | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Depth | 23 mm | Width | 0.82 in |
| Height | 0.31 in | Length | 1.3 in |
| Mounting Type | Screw | Mounting Style | Chassis |
| Length - Overall | 140 mm | Panel Mount Type | Open Frame |
| Size / Dimension | 5.51" L x 2.56" W x 1.02" H (140.0mm x 65.0mm x 26.0mm) | Number of Positions | 9 |
| Shell Size - Insert | 65 | ||
Product Info
| Type | Regulated | Style | Open Frame |
| Series | MTW | Application | Commercial |
| Applications | Commercial | Printed Circuit Board | 9 |
Environmental
| Operating Temperature | -10 to 60 °C | Operating Temperature - Junction | 60C |
