JWS10015/A
| Manufacturer | |
| Description | AC/DC Power Supply Single-OUT 15V 7A PWR SUP 15.0V 7A SNG OUTPUT Linear and Switching Power Supplies 15V 7A SWITCH MODE POWER SUPPLY PowerSupply;AC-DC;15V@7A;85-265VIn;Enclosed;PanelMount;PFC;JWSSeries |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Part # Aliases | JWS10015/A |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Standards | ULListed,CSACertified,EN60950,VDEApproved,CEApproved,BuilttoMeetDENTORI | Tariff No | 85359000 |
| Approval Agency | CE, CSA, DENTORI, EN, UL, VDE | ||
Electrical
| Output | 15VDC@7A | Frequency | 47 to 63 Hz |
| Operation | PFC | Efficiency | 77(Typ) % |
| Power (Watts) | 100W | Power - Output | 100W |
| Voltage Rating | 85 to 265 V | Load Regulation | 120mV |
| Current - Output | 7 A | Number of Outputs | 1 |
| Power Supply Type | Switching (Closed Frame) | Power (Watts) - Max | 105W |
| Voltage - Isolation | 3000VAC | Frequency - Operating | 63Hz |
| Voltage - Input (Min) | 15V | Voltage Regulation - Line | 60mV |
| Current - Output / Channel | 7 A | ||
Mechanical
| Width | 2.5 in | Height | 1.06 in |
| Length | 3.5 in | Weight | 9.876709 oz |
| Mounting Type | Desktop | Mounting Style | Chassis |
| Length - Overall | 187.96 | Primary Material | AC-DC |
| Size / Dimension | 7.40" L x 3.62" W x 1.97" H (188.0mm x 91.9mm x 50.0mm) | Shell Size - Insert | 50.04 |
Product Info
| Type | Standard Product | Style | Enclosed |
| Series | JWS | Features | Adjustable Output, DC Input Capable, PFC, Universal Input |
| Applications | Commercial | Manufacturer | JWSSeries |
| Configuration | Enclosed | ||
Environmental
| Operating Temperature | -10 to 50 °C | ||
