BK1005HS121-T
| Manufacturer | |
| Description | Ind Chip Bead Shielded Multi-Layer 120Ohm 25% 100MHz Ferrite 500mA 0402 T/R FERRITE BEAD 120 OHM 0402 EMI Filter Beads, Chips & Arrays FER BD MLCC 0402 120OHMS 25%, BK1005HS121-T Ferrite Beads Multi-Layer Chip Bead 120Ohm 25% 100MHz 500mA 0402 T/R |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Ferrite Chip Beads | Other Names | 587-1842-1 |
| Standard Package | Tape & Reel | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Impedance | 120 Ohm | Tolerance | 25 % |
| Filter Type | Differential Mode - Single | Test Frequency | 100 MHz |
| DC Resistance (DCR) | 200 mOhm Max | Current Rating (Max) | 500 mA |
| Impedance @ Frequency | 120 Ohm @ 100MHz | Resistance - Initial (Ri) (Min) | 200 mOhm |
Mechanical
| Width | 0.5 mm | Height | 0.55 mm |
| Packaging | Tape & Reel (TR) | Height (Max) | 0.022" (0.55mm) |
| Core Material | Ferrite | Mounting Type | Surface Mount |
| Package / Case | 0402 | Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Termination Style | SMD/SMT | ||
Product Info
| Type | Chip Bead | Series | BK |
Environmental
| Operating Temperature | - 55 C to + 125 C | ||
