RAPC732X
| Manufacturer | |
| Description | Phone Connectors R/A MINATURE PWR JK Conn Power PL 2 POS Solder RA Thru-Hole 3 Terminal 1 Port Bulk CONN JACK POWER R/A .05" PIN PCB CONNECTOR, DC POWER, SOCKET, 5A RightAnglePCMountDCPowerJack,pinsize0.050in(1.3mm) |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Phone Connectors | Standard Package | 1 |
| Factory Pack Quantity | 2500 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366910 | ||
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 1/4 in |
| Current Rating (Max) | 5A | Switch Function/Rating | Not Switched |
| Contact Rating @ Voltage | 5 A | ||
Mechanical
| Color | Black | Depth | 14.5 mm |
| Height | 11 mm | Weight | 0.002 |
| Packaging | Bulk | Shielding | Unshielded |
| AC Outlets | :1 | Orientation | Right Angle |
| Termination | Solder | Housing Color | Black |
| Mounting Type | Through Hole | Connector Type | Jack |
| Contact Finish | Nickel | Mounting Style | Through Hole |
| Contact Material | Brass | Housing Material | Thermoplastic |
| Length - Overall | 9 mm | Termination Style | Through Hole |
| Number of Contacts | 2 | Contact Termination | :Through Hole Vertical |
| Plug/Mating Plug Diameter | 1.27mm ID, 3.81mm OD | Contact Material - Plating | Nickel |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | Power | Gender | PL |
| Series | RAPC | Number of Ports | 1 |
| Internal Switch(s) | Single Switch, Normally Closed | Leaded Process Compatible | :Yes |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts | ||
