| Manufacturer | |
| Description | Phone Connectors 3C EXTENSION JACK Conn 1/4" Extension Jack F 3 POS Solder ST Cable Mount 3 Terminal 1 Port JACK EXTENSION .25" SHIELDED Jack; Phone; Panel Mount; 10 AWG; 3; Nickel Plated Copper Alloy Jack,Phone;PanelMount;10AWG;3;NickelPlatedCopperAlloy |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 44 Days | Tradename | Extension Jax |
| Subcategory | Connector Audio and Video | Product Category | Phone Connectors |
| Standard Package | 1 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Signal Lines | Stereo | Voltage - Supply | 1/4 in |
| Switch Function/Rating | Not Switched | ||
Mechanical
| Color | Metal | Shielding | Shielded |
| Termination | Solder | Housing Color | Silver |
| Mounting Type | Cable Mount | Connector Type | Phone Jack |
| Contact Finish | Nickel | Mounting Style | Cable |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Termination Style | Solder | Number of Contacts | 3 |
| Color - Actuator/Cap | Silver | Plug/Mating Plug Diameter | 6.35mm (0.250", 1/4") - Headphone |
| Contact Material - Plating | Nickel | ||
Product Info
| Type | 1/4" Extension Jack | Gender | F |
| Series | Extension Jax | Number of Ports | 1 |
| Internal Switch(s) | Does Not Contain Switch | Number of Positions/Contacts | 3 Conductors, 3 Contacts |
Environmental
| Operating Temperature | -55C to 125C | Operating Temperature - Junction | 125C |
