09GM4MX
| Manufacturer | |
| Description | DIN Connectors 4PIN 210DEG DIN PLUG Conn Circular DIN M 4 POS ST Cable Mount 4 Terminal 1 Port CONN DIN MALE PLUG 4POS STR GRAY DINCONNECTOR-ROHS |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | DIN Connectors | Standard Package | 1 |
| Factory Pack Quantity | 70 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Voltage Rating | 34VDC | Voltage - Supply | DIN |
| Current Rating (Max) | 3A | ||
Mechanical
| Color | Gray | Diameter | 17 mm |
| Packaging | Bulk | Cable Exit | Yes |
| Orientation | 3 | Termination | Solder |
| Contact Form | 4Signal | Contact Type | 4Signal |
| Mounting Type | Cable Mount | Shell Plating | Nickel |
| Angle of Throw | 210 | Connector Type | Plug, Male Pins |
| Contact Finish | Tin | Fastening Type | Push-Pull |
| Mounting Style | Cable | Length - Overall | 63.3 mm |
| Termination Style | Crimp | 1st Contact Gender | M |
| Number of Contacts | 4 | Number of Positions | 4 |
| Shell Size - Insert | DIN (210 Degree) | Shell Material, Finish | Zinc Die Cast, Nickel Plated |
Product Info
| Type | Circular DIN | Gender | PL |
| Series | DIN | Features | Cable Clamp, Shielded |
| Main Purpose | Cable Clamp, Shielded | Output Configuration | Free Hanging (In-Line) |
