RR0816P-222-D
| Manufacturer | |
| Description | Thin Film Resistors - SMD 1/16W 2.2Kohm 0.5% 25ppm RES 2.2K OHM 1/16W .5% 0603 SMD Thin Film Resistors 1/16W 2.2Kohm 0.5% 25ppm Res Thin Film 0603 2.2K Ohm 0.5% 1/16W �25ppm/C Molded SMD T/R |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Thin Film Resistors SMD | Other Names | RR08P2.2KDCT |
| Standard Package | 5,000 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Tolerance | 0.5 % | Resistance | 2.2 kOhms |
| Power - Max | 0.063W, 1/16W | Power (Watts) | 0.063W, 1/16W |
| Power - Rated | 62.5 mW (1/16 W) | Voltage Rating | 75 V |
| Resistance (Ohms) | 2.2k | Resistance in Ohms @ 25degC | 2.2k |
Mechanical
| Width | 0.8 mm | Height | 0.020" (0.50mm) |
| Packaging | Reel | Package / Case | 0603 (1608 metric) |
| Size / Dimension | 0.8 mm W x 1.6 mm L x 0.4 mm H | Termination Style | SMD/SMT |
| Number of Positions | 2 | Mounting Hole Diameter | 0603 |
| Number of Terminations | 2 | Supplier Device Package | 0816 |
Product Info
| Series | RR | DELETED | Compliant |
| Composition | Thin Film | ||
Environmental
| Operating Temperature | - 55 C to + 125 C | Temperature Coefficient | 25 PPM / C |
| Temperature Coefficient (Typ) | ±25ppm/°C | ||
