EE92251S1-000U-A99
| Manufacturer | |
| Description | FAN BRUSHLESS 92X92X25MM 12VDC Fan: DC; axial; 12VDC; 92x92x25mm; 87.55m3/h; 34dBA; slide bearing |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 140 Days | Subcategory | Not Specified |
| Standard Package | 200 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Material Flammability Rating | UL94V-0 |
Electrical
| Noise | 34 dB(A) | Speed | 3000 (±10%)rpm |
| Power (Watts) | 2.00W | Voltage Range | 4.5 ~ 13.8VDC |
| Voltage Rating | 12VDC | Voltage - Supply | 12V DC |
| Current Rating (Max) | 0.165A | Efficiency - Testing | 87.55m3/h |
| Insulation Resistance | 10MΩ | Voltage - Supply (Min) | 4.5...13.8V |
| Power - Average Forward | 2W | Current - Quiescent (Max) | ±15% |
Mechanical
| RPM | 3000 RPM | Weight | 0.207 lb (93.89g) |
| Air Flow | 51.5 CFM (1.46m³/min) | Fan Type | Tubeaxial |
| Insulation | A | Lead Style | 2 leads |
| Wire Gauge | 28AWG | Termination | 2 Wire Leads |
| Bearing Type | Sleeve | Cable Length | 300mm |
| Static Pressure | 0.150 in H2O (37.4 Pa) | Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Polybutylene Terephthalate (PBT) | Package Quantity | 50 |
| Size / Dimension | Square - 92mm L x 92mm H x 25mm W | Fan Accessory Type | 92x92x25mm |
| Exterior Housing Material | thermoplastic | Material - Housing & Prism | thermoplastic |
Product Info
| Spg | 50 | Features | AutoRestart |
| Function | Autorestart | Number of Units | 1 |
Environmental
| Rated Life | 50000 hrs @ 40°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
