VIPER06LS
| Manufacturer | |
| Description | AC to DC Switching Converter Off-Line Switcher 54kHz to 66kHz 10-Pin SSO SMPS SSOP-10 SMD IC OFFLINE SWITCH PWM 10-SSOP AC/DC Converters Fixed VIPer Plus 800V 60kHz 30mW |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 100 |
| Product Category | AC/DC Converters | Standard Package | 100 |
| Standard Package Name | SSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Leadfree Defin | RoHS-conform |
Electrical
| Frequency | 60000Hz | Power (Watts) | 8W |
| Frequency Range | 55kHz ~ 85kHz | Current - Output | 1.6 mA |
| Duty Cycle (Max) | 80 % | Output Isolation | Isolated |
| Voltage - Supply | 11.5 V | Number of Outputs | 1 |
| Current - Output 1 | 2.5A | Voltage - Breakdown | 800V |
| Frequency - Switching | 60 kHz | Voltage - Input (Min) | 4.8V |
Mechanical
| Width | 3.9 | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | SSOP-20 |
| Length - Overall | 4.9 | Package Quantity | SSO |
| Number of Positions | 10 | Shell Size - Insert | 1.25(Min) |
| Supplier Device Package | 10-SSO | ||
Product Info
| Type | SMPS | Matchcode | VIPER06LS |
| Standard Leadtime | 99 weeks | Printed Circuit Board | 10 |
Environmental
| Operating Temperature | -40°C | Maximum Temperature Limit | 150°C |
Documents & Media
PDF Document
