USBLC6-2P6
| Manufacturer | |
| Description | ESD Suppressor Diode Arrays 15KV 6-Pin SOT-666 T/R USB ESD PROTECTION SOT-666 TVS DIODE 5.25VWM 17VC SOT666 TVS Diode Array Uni-Directional USBLC6-2P6 17V, SOT-666 6-Pin TVS Diode Arrays High Speed Interface Protection Low Cap USBLC6-2P6 Integrated circuit: ESD protection; SOT666 TVS diode, 1.1 V SOT-666, USBLC6-2P6, ST STMicroelectronics 单向 TVS 二极管阵列, 17V, 6针 SOT-666封装 ESD Suppressors / TVS Diodes High Speed Interface Protection Low Cap |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 3000 |
| Other Names | 497-5026-1 | Product Category | TVS Diode Arrays |
| Standard Package | 3,000 | Factory Pack Quantity | 3000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Automotive | NO |
| ESD Protection | 15@Air Gap/15@Contact Disc kV | Leadfree Defin | RoHS-conform |
Electrical
| Channels | 2 Channels | Capacitance | 3.5 pF |
| Voltage Rating | 5 V | Current - Surge | 5 A |
| Voltage - Supply | 5.25V | Number of Elements | 2 |
| Voltage - Clamping | 17 V | Voltage - Breakdown | 6V |
| Contact Voltage (Max) | 5V | Power Line Protection | Yes |
| Bidirectional Channels | 2 | Voltage - Supply (Min) | 5 V |
| Current - Reverse Leakage @ Vr | 0.15 uA | Current - Peak Pulse (10/1000us) | 5A (8/20µs) |
Mechanical
| Weight | 0.05 g | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | SOT-666 | Package Quantity | 3000 |
| Size / Dimension | 1.7 mm W x 1.7 mm L x 0.6 mm H | Termination Style | SMD/SMT |
| Number of Positions | 6 | Supplier Device Package | SOT-666 |
Product Info
| Spg | 3000 | Type | Diode Arrays |
| Series | USBLC6-2 | Polarity | Bidirectional |
| Matchcode | USBLC6-2P6 | Applications | Ethernet |
| Port Direction | Uni-Directional | Number of Units | 1 |
| Standard Leadtime | 16 weeks | ||
Environmental
| Operating Temperature | -40 °C | ||
