STCN75DS2F
| Manufacturer | |
| Description | Temp Sensor Digital Serial (2-Wire, I2C) 8-Pin MSOP T/R IC TEMP SENSOR WTCHDG DGTL 8MSOP STCN75DS2F, 9bit Temperature Sensor ±3°C Serial-I2C 2.7 to 5.5V 8-Pin MSOP Board Mount Temperature Sensors Digital TEMP sensor thermal watchdog TEMPSENSOR,DIGITALWATCHDOG,8PINMSOP TEMPERATURE SENSOR WATCHDOG |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 497-6317-2 | Product Category | Board Mount Temperature Sensors |
| Standard Package | Tape & Reel | Factory Pack Quantity | 1000 |
| Standard Package Name | MSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Leadfree Defin | RoHS-conform |
Electrical
| Output | Serial | Accuracy | ±3(Max) °C |
| Interface | Serial (2-Wire, I2C) | Tolerance | ±3°C(Max) |
| Output Fan | No | Resolution | 9(Max) Bit |
| Output Type | Digital | Sensor Type | Internal |
| Number of Bits | 9 bit | Voltage Rating | 2.7 V |
| Current - Output | 150μA | Voltage - Supply | 2.7 to 5.5 V |
| Digital I/O Lines | 2-Wire, I2C, SMBus | Voltage - Input (Min) | 7.5V |
| Voltage - Supply (Min) | 5.5 V | Current - Collector Cutoff (Max) | 0.15 mA |
Mechanical
| Width | 3mm | Height | 0.85mm |
| Length | 3mm | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Termination | SurfaceMount |
| Mounting Type | Surface Mount | Mounting Style | SMD |
| Package / Case | 8MSOP | Package Cooled | MSOP |
| Top Termination | 125 °C | Package Quantity | MSOP |
| Primary Material | Thermostat | Size / Dimension | 3 x 3 x 0.85mm |
| Number of Positions | 8 | Minimum Working Height | -55 °C |
| Supplier Device Package | 8-MSOP | ||
Product Info
| Type | Temperature | Function | Temp Sensor |
| Topology | ADC (Sigma Delta), Comparator, Register Bank | Technology | ThermalConductive |
| Output Alarm | Yes | Configuration | Local |
Environmental
| Sensing Temperature | -55°C ~ 125°C | Operating Temperature | -55°C ~ 125°C |
| Temperature Coefficient | -55°C ~ 125°C | ||
