LM317K

Manufacturer	STMicroelectronics N.V.
Description	Standard Regulator Pos 1.2V to 37V 0.4A 3-Pin(2+Tab) TO-3 Bag VREG. ADJ 1,2-37V 1,5A TO3 IC REG LDO ADJ 1.5A TO3 LM317K, Linear Voltage Regulator, 1.5A Adjustable 1.2 to 37V, 3-Pin TO-3 IC, VOLT REG, 1.2V-37V, TO-3 CIRCUIT;TO-3;40V;0.01%/V(TYP.)LINEREGULATION;5MV(TYP.);1%;0.003%
Category	Integrated CircuitsPower Management ICsPower Management ICs

对参数有疑问？问 AI 助手

Business

MOQ	100	Unit Pack	100
Standard Package	Bag	Standard Package Name	TO-204-AA

Compliance

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85423990
Automotive	NO	Rad Hardened	No
Leadfree Defin	RoHS-conform

Electrical

Output	0.003%	Output Type	Adjustable
Regulator Type	Linear	Voltage Rating	1.2 to 37 V
Line Regulation	0.04 %/V	Load Regulation	0.5 %
Current - Output	0.4(Typ) A	Voltage - Supply	80dB
Number of Outputs	1	Voltage Reference	1.3 V
Regulator Topology	Positive Adjustable	Overload Protection	YES
Resistance @ 25degC	4°C/W	Number of Regulators	1
Noise - 0.1Hz to 10Hz	0.003%/V	Voltage - Input (Min)	1.2 V ~ 37 V
Voltage - Output (Max)	:37V	Power Dissipation (Max)	InternallyLimited
Differential - Input:Output	40V	Voltage - Output (Min/Fixed)	:1.2V
Voltage - Continuous Operating (Max) (MCOV)	:40V

Mechanical

Width	26.2(Max)	Weight	0.0115
Packaging	Bag	Tab Width	Tab
Lead Style	Through Hole	Mounting Type	Through Hole
Number of Pins	:3	Package / Case	3TO-3
Package Cooled	TO-3	Material Finish	:-
Length - Overall	39.5(Max)	Package Quantity	TO-3
Number of Positions	3	Shell Size - Insert	8.7(Max)
Supplier Device Package	TO-3

Product Info

Mode	ADJ	Type	Linear
Features	Current Limit\|Thermal Shutdown Pr...	Polarity	Positive
Topology	Standard	Matchcode	LM317K
Adjustment Type	50μA(Typ.)	Standard Leadtime	26 weeks
Other Specifications	:1.2V to 37V	Printed Circuit Board	2

Environmental

Temperature	1%	Operating Temperature	0 to 125 °C
Usable Temperature Range	0to+125°C	Operating Temperature - Junction	125°C
