L6565DTR
| Manufacturer | |
| Description | Current Mode PWM Controller 400mA 8-Pin SO N T/R SMPS SO-8 SMD IC CTCLR PWM SMPS CM UVLO 8SOIC Switching Controllers Current-Mode Pri Cnt |
| Category |
Business
| MOQ | 2500 | Unit Pack | 2500 |
| Other Names | 497-4584-6 | Standard Pack | 2,500 |
| Product Category | Switching Controllers | Standard Package | Tape & Reel, Cut Tape |
| Factory Pack Quantity | 2500 | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Rad Hardened | No |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Fall Time | 40 ns | Power (Watts) | 650mW |
| Voltage Rating | 10.3 | Rise Time (Typ) | 40 ns |
| Current - Output | 400(Max) mA | Current - Supply | 3.5 mA |
| Output Isolation | Isolated | Voltage - Supply | 10.3 V to 18 V |
| Number of Outputs | 1 | Current - Output 1 | 0.7A |
| Frequency - Switching | 70 kHz | Synchronous Rectifier | No |
| Voltage - Input (Min) | 18V | Voltage - Supply (Min) | 18 V |
| Number of Outputs and Type | 1 | ||
Mechanical
| Width | 4(Max) | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Contact Form | No |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 8SO N | Package Cooled | SO N |
| Length - Overall | 5(Max) | Package Quantity | SO N |
| Number of Positions | 8 | Shell Size - Insert | 1.65(Max) |
| Supplier Device Package | 8-SO | ||
Product Info
| Type | SMPS | Topology | Flyback |
| Matchcode | L6565DTR | Control Method | Current Mode PWM Controller |
| Standard Leadtime | 15 weeks | Output Configuration | No |
| Printed Circuit Board | 8 | ||
Environmental
| Operating Temperature | -40 to 150 °C | Maximum Temperature Limit | 150°C |
Documents & Media
Similar Parts
STEVAL-ISA015V2
stmicroelectronics
Evaluation Board For 3Phase Power Supply Evaluation Board With ESBT Power Management IC Development Tools BOARD & REF DESIGN BOARD EVAL 3PHASE W/ESBT 100W
STEVAL-ISA034V1
stmicroelectronics
Evaluation Board For 10 W 3Phase Auxiliary Power Supply Based On The L6565 And Stw3N150 Evaluation Board Power Management IC Development Tools 10W 3Phase Aux Pwr Supply BRD BOARD EVAL L6565/STW3N150
STEVAL-ISA016V1
STMicroelectronics
Power Management IC Development Tools QUASI-RESONANT Flyback Converter Power Supply For STB Based On L6565 Evaluation Board BOARD EVAL L6565 EU220V BASED
STEVAL-TSP001V1
stmicroelectronics
Power Over Ethernet Demonstration Board Based On The L6565 Power Management IC Development Tools PoE Eval Brd EvalBoard STHS4257A PoE Powere BOARD EVAL POE STHS4257A/L6565D
STEVAL-ISC001V1
stmicroelectronics
Evaluation Board For 30 W ACDC Adapter Based On The L6565 Power Management IC Development Tools 30W AC-DC Adapter Based on L6565 BOARD EVAL BASED ON L6565 Evaluation Board 30 W AC-DC Adapter Based on L6565
STEVAL-ISA019V2
stmicroelectronics
QuasiResonant Wide Range SMPS Demonstration Board Based On The L6565 For 3Phase Applications Power Management IC Development Tools BOARD & REF DESIGN BOARD EVAL SMPS L6565 3PHASE APP
STEVAL-ISA041V1
stmicroelectronics
SMPS Based 125 W On The STP12Ie95F4 ESBT Switch With L6565 PWM Controller Power Management IC Development Tools 125W SMPS STP12IE95X L6565 PWM STSR30 REC BOARD EVAL STP12IE95F4
