L6386ED
| Manufacturer | |
| Description | MOSFET DRVR 600V 0.65A 2-OUT Hi/Lo Side Half Brdg Non-Inv 14-Pin SOIC Tube HaBr MOSvIGBTDr 600V SO-14 SMD IC DRIVER HIGH/LOW SIDE 14-SOIC L6386ED, Dual MOSFET Power Driver 0.65A Half Bridge, Non-Inverting, Maximum of 17V, 14-Pin SOIC Gate Drivers Hi-Vltg and Lo Side Driver DRIVER, MOSFET, IGBT, 600V, 0.65A, 14SO Driver; high/low side; 400mA; -3÷600V; Channels:2; SO14 STMicroelectronics 双 MOSFET 功率驱动器, 0.65A, 半桥, 非反相, 14针 SOIC封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1000 | Product | H-Bridge Drivers |
| Unit Pack | 50 | Product Category | Gate Drivers |
| Standard Package | Rail / Tube | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423300 |
| Automotive | NO | Rad Hardened | No |
| Leadfree Defin | RoHS-conform | Fault Protection | NANY/N/NA/NAN |
Electrical
| Fall Time | 30 ns | Frequency | 0.4 MHz |
| Delay Time | 110ns | Input Type | Non-Inverting |
| Power - Rated | 0.75 W | Voltage Rating | -3...600V |
| Delay Time - ON | 0.15 us | Frequency - Max | 0.4 MHz |
| Rise Time (Typ) | 50(Typ) ns | Current - Output | 400mA |
| Delay Time - OFF | 0.00015 ms | Driver Circuitry | High and Low Side |
| Voltage - Supply | 17V | Number of Outputs | 2 |
| Number of Channels | 2 | Current - Peak Output | 0.65 A |
| Voltage - Input (Min) | 600V | Voltage - Supply (Min) | 17 V |
| Input Logic Level - Low | CMOS/TTL | Power Dissipation (Max) | 750 mW |
| Delay Time - Propagation | 150 ns | Input Logic Level - High | CMOS|TTL |
| On-State Resistance (Max) | NY/N/NA/NAN | VoP, Velocity of Propagation | 17V |
| Current - Peak Pulse (10/1000us) | 400mA | Current - Leakage (IS(off)) (Max) | NY/N/NA/NAN |
| Max Propagation Delay @ V, Max CL | 30(Typ) ns | High Side Voltage - Max (Bootstrap) | 600V |
| Propagation Delay tpLH / tpHL (Max) | 150 | ||
Mechanical
| Width | 4mm | Height | 1.65mm |
| Length | 8.75mm | Weight | 0.0001 |
| Packaging | Tube | Case Color | :SOIC |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :14 |
| Package / Case | 14SOIC | Package Cooled | SO |
| Material Finish | :MSL 3 - 168 hours | Length - Overall | 8.75(Max) |
| Package Quantity | SOIC | Size / Dimension | 8.75 x 4 x 1.65mm |
| Number of Positions | 14 | Shell Size - Insert | 1.65(Max) |
| Supplier Device Package | 14-SO | ||
Product Info
| Spg | 100 | Type | High Side/Low Side |
| Matchcode | L6386ED | Configuration | High and Low Side, Independent |
| Number of Units | 1 | Module/Board Type | :High Side, Low Side |
| Number of Drivers | 2 | Standard Leadtime | 13 weeks |
| Utilized IC / Part | high/low side | Motor Type - AC, DC | Half Bridge |
| Printed Circuit Board | 14 | Number of Configurations | 1 |
Environmental
| Operating Temperature | -45 to 125 °C | Operating Temperature - Junction | -40°C |
