L6228Q

Manufacturer	STMicroelectronics N.V.
Description	Stepper Motor Driver 32-Pin VFQFPN EP StepMotDr 1.4A 52V QFN5x5 SMD IC MOTOR DRIVER PAR 32VFQFPN Motor / Motion / Ignition Controllers & Drivers DMOS Dual Full Bridge w/ PWM MOTOR DRIVER, DMOS, BIPLR, 2.8A, 32QFN
Category	Integrated CircuitsPower Management ICsPower Management ICs

对参数有疑问？问 AI 助手

Business

MOQ	2940	Product	Stepper Motor Controllers / Drivers
Unit Pack	490	Product Category	Motor / Motion / Ignition Controllers & Drivers
Standard Package	Trays	Standard Package Name	QFN

Compliance

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85423990
Automotive	NO	Leadfree Defin	RoHS-conform

Electrical

Interface	Parallel	Voltage - Load	8 V ~ 52 V
Voltage Rating	:52V	Current - Output	1.4A
Voltage - Supply	8 V ~ 52 V	Number of Outputs	:2
Voltage - Supply (Max)	5.5 V	Voltage - Supply (Min)	52

Mechanical

Weight	0.0069	Packaging	Tray
Case Color	:VFQFPN	Lead Style	No Lead
Motor Type	:Stepper	Mounting Type	Surface Mount
Mounting Style	SMD/SMT	Number of Pins	:32
Package / Case	32VFQFPN EP	Material Finish	:MSL 3 - 168 hours
Package Quantity	VFQFPN EP	Number of Positions	32
Supplier Device Package	32-VFQFPN Exposed Pad (5x5)

Product Info

Type	Stepper Motor Driver	Function	Driver - Fully Integrated, Control and Power Stage
Matchcode	L6228Q	Applications	General Purpose
Standard Leadtime	12 weeks	Motor Type - Stepper	Bipolar
Output Configuration	Full H-Bridge, (1) Single

Environmental

Temperature - Test	-25°C	Operating Temperature	-40 to 150 °C
Maximum Temperature Limit	125°C

Documents & Media

PDF Document

CD00182152.pdf

PDF Document

1698028.pdf
