ESDALC6V1-5P6
| Manufacturer | |
| Description | ESD Suppressor Diode Arrays ±15KV 6-Pin SOT-666 T/R TVS DIODE 5VWM 14VC SOT666 TVS Diode Arrays EMI Filter ESD TRANSIL ARRAY UNI ESD SOT-666 STMicroelectronics 单向 TVS 二极管, 30W, 14V, 6针 SOT-666封装 ESD Suppressors / TVS Diodes EMI Filter ESD |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 497-7229-1 | Product Category | TVS Diode Arrays |
| Standard Package | Tape & Reel | Factory Pack Quantity | 3000 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85412900 |
| ESD Protection | ±15@Air Gap/±8@Contact Disc | ||
Electrical
| Channels | 5 Channels | Capacitance | 15 pF |
| TVS Polarity | :Unidirectional | Voltage Rating | 5 V |
| Current - Surge | 2.5 A | Voltage - Supply | 5V (Max) |
| Number of Elements | 5 | Power - Peak Pulse | 30W |
| Voltage - Clamping | 14 V | Capacitance @ Vr, F | :15pF |
| Diode Configuration | :SOT-666 | Voltage - Breakdown | 6.1V |
| Voltage - Isolation | :3V | Power Line Protection | No |
| Capacitance @ Frequency | 12pF @ 1MHz | Unidirectional Channels | 5 |
| Current - Peak Pulse (8/20us) | :2.5A | Current - Reverse Leakage @ Vr | 0.07 uA |
| Current - Peak Pulse (10/1000us) | 2.5A (8/20µs) | ||
Mechanical
| Weight | 0.00195 | Packaging | Tape and Reel |
| Lead Style | Flat | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :6 | Package / Case | SOT-563, SOT-666 |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | SOT-666 |
| Size / Dimension | 1.3 mm W x 1.7 mm L x 0.6 mm H | Termination Style | SMD/SMT |
| Number of Positions | 6 | Supplier Device Package | SOT-666 |
Product Info
| Type | Diode Arrays | Series | ESDALC6V1-5P6 |
| Polarity | Unidirectional | Diode Type | :Unidirectional |
| Applications | General Purpose | Configuration | Quint |
| Port Direction | Uni-Directional | ||
Environmental
| Operating Temperature | -40 °C | ||
