BD139

Manufacturer	STMicroelectronics N.V.
Description	Trans GP BJT NPN 80V 3A 3-Pin(3+Tab) SOT-32 Tube NPN TRANSISTOR 80V 1,5A SOT32 TRANSISTOR NPN SOT-32 BD139, NPN Bipolar Transistor, 3A 80V HFE:25V Power, 3-Pin SOT-32 Transistors Bipolar - BJT NPN Audio Amplifier TRANSISTOR, NPN, 45V, 1.5A, SOT-32 TRANSISTOR,NPN,1.5A80V,TO126PKG Transistor: NPN; bipolar; 80V; 1.5A; 12W; TO126 Power transistor TO-126 NPN 80 V, BD139, ST STMicroelectronics , NPN 晶体管, 3 A, Vce=80 V, HFE:25, 3针 SOT-32封装 Bipolar Transistors - BJT NPN Audio Amplifier
Category	Discrete Semiconductor ComponentsBipolar TransistorsBipolar Transistors - General

对参数有疑问？问 AI 助手

Business

MOQ	50	Unit Pack	50
Product Category	Transistors Bipolar - BJT	Standard Package	Rail / Tube
Factory Pack Quantity	50	Standard Package Name	TO-126

Compliance

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85412900
Rad Hardened	No	Leadfree Defin	RoHS-conform

Electrical

Frequency	50MHz	Power - Max	1.25W
Power - Rated	1.25 W	Transistor Type	NPN
Voltage - Supply	80V	Number of Elements	1
Resistance @ 25degC	10°C/W	Vce Saturation (Max)	- 0.5 V, + 0.5 V
Voltage - Input (Min)	80 V	Voltage - Supply (Max)	5 V
Power Dissipation (Max)	1250 mW	Vce(on) (Max) @ Vge, Ic	80V
Power (Watts) - Per Port	12.5W	Vce Saturation (Max) @ Ib, Ic	500mV @ 50mA, 500mA
Current - Collector (Ic) (Max)	1.5A	Current - Collector Cutoff (Max)	3 A
DC Current Gain (hFE) (Min) @ Ic, Vce	25@5mA@2V\|25@500mA@2V\|40@150mA@2V	Voltage - Collector Emitter Breakdown (Max)	5 V

Mechanical

Width	2.7mm	Height	10.8mm
Length	7.8mm	Weight	0.00064
Packaging	Tube	Lead Style	Through Hole
Termination	:Through Hole	Mounting Type	Through Hole
Mounting Style	SMD/SMT	Number of Pins	:3
Package / Case	3SOT-32	Package Cooled	SOT-32
Material Finish	:-	Package Quantity	SOT-32
Primary Material	Si	Size / Dimension	10.8 x 7.8 x 2.7mm
Number of Positions	3	Supplier Device Package	SOT-32-3

Product Info

Spg	2000	Type	NPN
Polarity	NPN	Matchcode	BD139
Card Standard	Bipolar Power	Configuration	Single
Number of Units	1	Standard Leadtime	12 weeks
Utilized IC / Part	:BD139

Environmental

Operating Temperature

-65 to 150 °C

Documents & Media

PDF Document

CD00001225.pdf

PDF Document

BD1xx

PDF Document

1689713.pdf
