1N6263
| Manufacturer | |
| Description | Diode Small Signal Schottky 60V 0.015A 2-Pin DO-35 DIODE SCHOTTKY 60V 0.015A DO35 1N6263, Schottky Diode, 0.015A 60V, 2-Pin, DO-35 Schottky Diodes & Rectifiers 15mA 60 Volt DIODE, RF, SCHOTTKY DIODE,SCHOTTKY,60V15MADO-35PKG Diode: Schottky switching; 60V; 1mA; 15mA; DO35; 0.1ns Schottky diode 15 mA 60 V DO-35, 1N6263, ST STMicroelectronics 肖特基 二极管, 15mA 60V, 2针 DO-35封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Schottky Diodes | Other Names | 497-2508-2 |
| Product Category | Schottky Diodes & Rectifiers | Standard Package | Tape & Reel |
| Factory Pack Quantity | 4000 | Standard Package Name | DO-204-AH |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Rad Hardened | No | ||
Electrical
| Speed | Small Signal = | Capacitance | :2.2pF |
| Load Current | 1mA | Current - Test | 0.2@50V uA |
| Current - Surge | :50mA | Current - Output | 0.2μA |
| Voltage - Supply | 1 V | Capacitance @ Vr, F | 2.2pF @ 0V, 1MHz |
| Diode Configuration | :Single | LED Forward Voltage | 1 |
| Voltage - Breakdown | :60V | Voltage - Off State | 60V |
| Current Rating (Max) | :10µA | Frequency - Switching | Ultrafast |
| Voltage - Input (Min) | 1V @ 15mA | Power Dissipation (Max) | :400mW |
| Delay Time - Propagation | 100ps | Voltage Regulation - Load | 60 V |
| Reverse Recovery Time (trr) | 0.1ns | Current - Peak Pulse (8/20us) | 0.05 A |
| Current - Reverse Leakage @ Vr | 0.2 uA at 50 V | Current - DC Forward (If) (Max) | :15mA |
| Voltage - DC Reverse (Vr) (Max) | 60V | Current - Average Rectified (Io) | 0.015 A |
| Current - Peak Pulse (10/1000us) | 0.00005kA | Voltage - Reverse Standoff (Typ) | 60 V |
| Current - LED Trigger (Ift) (Max) | :15mA | Current - Continuous Drain (Id) @ 25degC | 0.015A |
Mechanical
| Width | 2mm | Height | 2mm |
| Length | 4.5mm | Weight | 0.000137 |
| Packaging | Tape & Reel (TR) | Lead Style | Through Hole |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Number of Pins | :2 | Package / Case | 2DO-35 |
| Package Cooled | DO-35 | Length - Overall | 4.5(Max) |
| Package Quantity | DO-35 | Primary Material | Switching |
| Size / Dimension | 2 x 4.5 x 2mm | Diameter - Outside | :1.85mm |
| Number of Positions | 2 | Supplier Device Package | DO-35 |
Product Info
| Spg | 4000 | Type | Small Signal Schottky Diode |
| DELETED | Compliant | Diode Type | Schottky |
| Configuration | Single | Number of Units | 1 |
| Printed Circuit Board | 2 | ||
Environmental
| Thermal Resistance | 400°C/W Ja | Operating Temperature | -65 to 200 °C |
| Thermal Resistance @ Natural | 400K/W | Operating Temperature - Junction | -65°C ~ 200°C |
