MK06-4-B
| Manufacturer | |
| Description | Proximity Sensors 1 Form A SIL SENSOR MAGNETIC REED PCB MNT Reed sensor 1 make contact (NO) 30 V 0.1 A, MK06-4-B, Standex-Meder |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | 2206040001 | Product Category | Proximity Sensors |
| Standard Package | 500 | Factory Pack Quantity | 500 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Circuit | SPST-NO | Power - Max | 10W |
| Current - Output | 0.5 A | Sensing Distance | 15 mm |
| Voltage - Supply | 170 V | Switching Voltage | 170V |
| Switching Capacity | 1 W | Current - Switching | 500mA |
| Power - Average Forward | 10W | Voltage - Supply Span (Max) | 170V |
| Current - Peak Pulse (10/1000us) | 500mA | ||
Mechanical
| Packaging | Bulk | Mounting Type | PCB, Through Hole |
| Mounting Style | Radial | Material - Magnet | Not Specified |
| Termination Style | PC Pin, Radial | Number of Contacts | 1 make contact (NO) |
Product Info
| Type | Molded Body | Series | MK06 |
| Circuit Type | SPST-NO | Accessory Type | Not Specified |
| Sensing Method | Magnetic | Output Configuration | PCB, Through Hole |
Environmental
| Must Operate | 10 ~ 15AT | Operating Temperature | - 20 C |
