STGIPS20C60
| Manufacturer | |
| Description | IPM SDIP-25L MO MOD IPM SLLIMM 20A 600V 25SDIP IGBT Modules 600V 20A SLIMM 3-Ph Trench Gate IGBT Small Low Loss Intelligent Molded Module 25-Pin SDIP Tube STMicroelectronics SLLIMM Intelligent Power Module 系列 三相交流电机驱动器 , 用于交流感应, 20A SMART 600V 20A 1,6V SDIP-25L |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 132 | Product | IGBT Silicon Modules |
| Tradename | SLIMM | Unit Pack | 11 |
| Other Names | 497-13759-5 | Standard Package | 11 |
| Factory Pack Quantity | 132 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Automotive | NO |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Current | 20A | Voltage | 600V |
| Power - Rated | 46 W | Voltage - Supply | 600 V |
| Voltage - Isolation | 2500Vrms | Current Rating (Max) | 20A |
| Vce Saturation (Max) | 1.7 V | Power - Average Forward | 46 W |
| Vce(on) (Max) @ Vge, Ic | 600 V | Power (Watts) - Per Port | 46 W |
| Current - Collector (Ic) (Max) | 20 A | Current - Collector Cutoff (Max) | 20A |
| Current - Collector Pulsed (Icm) | 40 A | Current - Continuous Drain (Id) @ 25degC | 20 A |
Mechanical
| Width | 22.5mm | Height | 6mm |
| Length | 44.9mm | Packaging | Tube |
| Motor Type | 交流感应 | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Number of Pins | 25 |
| Package / Case | 25-DIP Module | Package Cooled | SDIP |
| Package Quantity | SDIP | Size / Dimension | 44.9 x 22.5 x 6mm |
| Number of Positions | 25 | ||
Product Info
| Type | IGBT | Series | SLLIMM™ |
| Technology | SLLIMM | Manufacturer | STMicroelectronics |
| Configuration | 3 Phase Inverter | Channels per IC | 3 Phase Inverter |
| Output Configuration | 3 相 | ||
Environmental
| Operating Temperature | - 40 C | Sensing Temperature - Local | NO |
| Operating Temperature - Junction | 150C | ||
