UTG018-23P

Business

Tradename	Trim Trio	Product Category	Standard Circular Connector
Standard Package	1	Factory Pack Quantity	25

RoHS

Compliant

Frequency	33.1	Voltage Rating	500
Number of Poles	23	Current Rating (Max)	13 A

Outline	18	Packaging	Bulk
Shell Size	18	Orientation	Keyed
Shell Style	Square Flange	Contact Size	16
Contact Type	Crimp	Mounting Type	Panel Mount, Flange
Connector Type	Receptacle for Male Contacts	Fastening Type	Bayonet Lock
Mounting Style	Wall	Shell Material	Thermoplastic
Connector Style	with flange	Insertion Angle	18-23
Locking Feature	Bayonet locking	Contact Material	CuNi+Au
Housing Material	Metal	Termination Rows	焊接
Termination Style	Crimp Connection	1st Contact Gender	Without Pin Contacts
Diameter - Outside	28.5	Number of Contacts	23
Number of Positions	23	Shell Size - Insert	18-23
1st Connector Gender	Male	Shell Material, Finish	Thermoplastic, Glass Filled
