SMS2P1

Business

Other Names	SOU1217	Product Category	Headers & Wire Housings
Standard Package	100	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85369010	Material Flammability Rating	:UL94V-2

Voltage Rating	2 kV	Switch Function	Latched
Current Rating (Max)	5 A

Depth	32.9 mm	Pitch	0.200" (5.08mm)
Height	15 mm	Weight	0.004
Material	:Polyamide	Contact Type	Male or Female
Mounting Type	Straight	Connector Type	Plug
Contact Finish	Gold	Fastening Type	Latch Lock
Number of Rows	1	Panel Thickness	:2.3mm
Contact Material	Copper Alloy	Housing Material	Polyamide 6.6
Length - Overall	17.8 mm	1st Contact Gender	Pin (Male)
Color - Connectors	:Black	Number of Contacts	2
Panel Cutout Shape	:11.4x11.6mm	Contact Termination	Crimp
Number of Positions	2	Diameter - Outside, Non-Expanded	:8.4mm

Note	Contacts Not Provided	Type	Housing
Gender	PL	Series	SMS
Product Type	Plugs - Housings	For Use With/Related Products	:SMS - Qikmate Panel and Cable Connectors
