MGPM40TF-50Z
| Category |
对参数有疑问?问 AI 助手
Compliance
| RoHS | Compliant | ||
Electrical
| Speed | 50...500 mm/s | ||
Mechanical
| Width | 48mm | Height | 112mm |
| Length | 147mm | Weight | 2.37kg |
| Air Flow | G1/8 | Diameter | 40mm |
| Base Type | Compact cylinder | Boreholes | 40mm |
| Cushioning | Rubber Bumper | Shaft Size | Single |
| Actuator Type | 双 | Stroke Length | 50mm |
| Connector Type | M5 | Size / Dimension | 147 x 112 x 48mm |
| Diameter - Barrel | 40 | Maximum Pressure (PSI) | 1 MPa |
| Thread/Screw/Hole Size | 4 x M8 | ||
Product Info
| Function | Double | Port Style | G 1/8 |
| Adapter Series | MGP | Other Specifications | 橡胶 |
Environmental
| Operating Pressure | 0.12...1.0 MPa | Operating Temperature | +60°C |
