PW170KB0903B01
| Manufacturer | |
| Description | AC/DC Power Supply Single-OUT 9V 1.5A 13.5W Plug-In Adapter Single-OUT 9V 1.5A 13.5W PS EXT 15W 9V @ 1.50A E-STAR Plug-In AC Adapters 15.0W 9V 1.50A Energy Star IV POWERSUPPLY,9VDC,1.5AMPS,13.5WATTS |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 112 Days | Other Names | 271-2576 |
| Subcategory | External Plug-In Adapter | Product Category | Plug-In AC Adapters |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Protection | Overload|Short Circuit|Over Voltage | Approval Agency Marking | CSA/EN/IEC/UL |
Electrical
| Noise | 1%(Max) | Output | 9VDC@1.5A |
| Frequency | 47 to 63 Hz | Operation | Switching |
| Efficiency | Level IV | Output Fan | Cylindrical Female |
| Output Type | Fixed | Power - Max | 13.5 W |
| Output Power | 13.5 W | Power (Watts) | 13.5W |
| Power - Input | No | Power - Output | 13.5W |
| Voltage Rating | 100 to 240 V | Line Regulation | 1% |
| Load Regulation | 5% | Current - Output | 1.5 A |
| Voltage - Supply | 100 ~ 240 VAC | Number of Outputs | 1 |
| Power Supply Type | Switching | Voltage - Isolation | 3000VAC |
| Current Rating (Max) | 1.5A | Voltage - Input (Min) | 9V |
| Rise / Fall Time (Typ) | 18(Min)@115VAC | Voltage - Output (Max) | 9V |
| Current - Input Bias (Max) | 0.4@90VAC | Current - Output / Channel | 1.5 A |
Mechanical
| Width | 46 | Cord Length | 70.87" (1.8m) |
| Polarization | Positive Center | 1st Connector | IEC Male |
| Mounting Type | Desktop | Connector Type | 2.5mm I.D. x 5.5mm O.D. x 9.5mm Female |
| Mounting Style | Wall, Interchangeable Plug | Length - Overall | 84 |
| Output Connector | Center Positive | Primary Material | AC-DC |
| Color - Connectors | Black | Shell Size - Insert | 32 |
| Connector - AC Output | Included | ||
Product Info
| Form | Wall Mount (Multi Plug - Sold Separately) | Type | Linear |
| Style | Interchangeable WallMount | Series | PW170KB |
| Features | OCP, OVP, SCP | Polarity | Positive Center |
| Application | Commercial | Composition | Wall Mount (Multi Plug - Sold Separately) |
| Applications | Commercial | Manufacturer | PW170KBSeries |
| Configuration | Enclosed | Region Utilized | North America |
Environmental
| Operating Temperature | 0 to 40 °C | ||
Documents & Media
PDF Document
PDF Document
