GSC20-24G
| Manufacturer | |
| Description | AC/DC Power Supply Single-OUT 24V 0.85A 20W 8-Pin PWR SPLY SWITCHING 24V .85A POWERSUPPLY,SWITCHING;20W;90TO264VAC;24V;0.6A(MAX.);0.85A;0.75% |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Approval Agency | CE, CSA, EN, IEC, UL |
Electrical
| Output | 24VDC@0.85A | Frequency | 47 to 63 Hz |
| Operation | Switching | Efficiency | 70(Min) % |
| Power - Max | 20 W | Output Power | 20 W |
| Power (Watts) | 20W | Power - Output | 20W |
| Voltage Rating | 90 to 264 V | Load Regulation | 0.75% |
| Current - Output | 0.85 A | Number of Outputs | 1 |
| Power Supply Type | Switching (Open Frame) | Power (Watts) - Max | 20W |
| Current Rating (Max) | 0.6 A | Voltage - Input (Min) | 24V |
Mechanical
| Depth | 50.8 mm | Width | 50.8 |
| Height | 18.03 mm | Mounting Type | Screw |
| Mounting Style | Screw | Length - Overall | 88.9 mm |
| Primary Material | AC-DC | Size / Dimension | 3.50" L x 2.00" W x 0.71" H (88.9mm x 50.8mm x 18.0mm) |
| Number of Positions | 8 | Shell Size - Insert | 18.03 |
Product Info
| Type | Switching | Style | Open Frame |
| Features | OvervoltageProtectionStandard | Applications | Commercial |
| Manufacturer | GLC20Series | Configuration | OpenFrame |
| Printed Circuit Board | 8 | ||
Environmental
| Operating Temperature | 0°C ~ 50°C | ||
