TS12011ITD1022T
| Manufacturer | |
| Description | IC OP AMP COMPARATOR REF 10TDFN IC OPAMP GP 15KHZ RRO 10TDFN Op Amp/Comp/Ref, 0.8-2.5V,PP,RRO,DFN10 OP AMP, 15KHZ, 6000V/US, 7000UV, DFN-10 Silicon Labs 精确 运算放大器, 15kHz 轨至轨, 0.8 → 2.5 V, 10针 μDFN |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | TS12011ITD1022TTR | Standard Package | 3,000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85423300 |
Electrical
| Slew Rate | 0.006 V/µs | Output Type | Phase Reversal Free, Rail to Rail |
| Transistor Type | :- | Current - Output | 1.1µA |
| Voltage - Supply | 0.8 V ~ 2.5 V | Power Supply Type | Single |
| Number of Channels | 1 | Current - Input Bias | 20nA |
| Number of ADCs / DACs | :1 | Voltage - Input (Min) | 3.5mV |
| Gain Bandwidth Product | 15kHz | Current - Output / Channel | 500µA |
| Voltage - Output Difference (Typ) @ Distance | 104 dB | ||
Mechanical
| Width | 2mm | Height | 0.55mm |
| Length | 2mm | Weight | 0.000012 |
| Bandwidth | :15kHz | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Number of Pins | :10 |
| Package / Case | 10-UFDFN Exposed Pad | Package Cooled | μDFN |
| Material Finish | :MSL 1 - Unlimited | Size / Dimension | 2 x 2 x 0.55mm |
| Number of Positions | 10 | Supplier Device Package | 10-TDFN (2x2) |
Product Info
| Amplifier Type | General Purpose | Number of Circuits | 1 |
| Output Configuration | :CMOS | ||
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
