SX1233IMLTRT
| Manufacturer | |
| Description | RF Transceiver FSK/GFSK/MSK/GMSK/OOK 2.5V/3.3V 24-Pin QFN EP T/R IC 433/868/915MHZ TXRX 24-QFN LOW-POWER INTG UHF TRANSCEIVER ; HT SUSA CODE:8542310000 RF Transceiver LOW-POWER INTG UHF TRANSCEIVER |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | SX1233IMLTRTTR | Standard Package | 3,000 |
| Factory Pack Quantity | 3000 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 433MHz, 868MHz, 915MHz | Interface | SPI |
| Modulation | FSK|GFSK|MSK|GMSK|OOK | Sensitivity | -120dBm |
| Output Power | - 18 dBm to + 17 dBm | Data Interface | PCB, Surface Mount |
| Power - Output | 17dBm | Voltage Rating | 1.8V |
| Data Rate (Max) | 600kbps | Frequency - Max | 928 |
| Frequency Range | 290 MHz to 340 MHz, 424 MHz to 510 MHz, 862 MHz to 1.02 GHz | Current - Supply | 16 mA |
| Voltage - Supply | 1.8 V ~ 3.6 V | Current - Receiving | 17mA |
| Current - Transmitting | 95mA | Voltage - Supply (Min) | 3.6V |
| Current - Supply (Main IC) | 95 mA | ||
Mechanical
| Width | 5 | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | * |
| Length - Overall | 5 | Package Quantity | QFN EP |
| Antenna Connector | PCB, Surface Mount | Number of Positions | 24 |
| Shell Size - Insert | 0.95(Max) | ||
Product Info
| Type | ISM | Series | SX1233 |
| Applications | AMR, ISM, Home Automation, Process Control | Manufacturer | Semtech |
| Number of Receivers | 1 | Printed Circuit Board | 24 |
| Modulation or Protocol | FSK, GFSK, GMSK, MSK, OOK | Number of Transmitters | 1 |
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
