SKKH57/16E..
| Manufacturer | |
| Description | THYRISTOR MODULE, 60A, 1600V THYRISTOR/DIODE MODULE, 60A, 1600V Thyristor;Line;55AOn-State(Avg.Max.);1500A;95AIT(RMS);SemipackCase Diode-thyristor power module; 1.6kV; 55A; SEMIPACK1 Thyristor diode module SEMIPACK 1 1600 V, SKKH57/16E, Semikron |
| Category |
对参数有疑问？问 AI 助手
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85413000 |
Electrical
| SCR Type | :A 46 | Transistor Type | diode-thyristor power module |
| Voltage - Isolation | :2.5kV | Voltage - Off State | 1.6kV |
| Current Rating (Max) | 55A | Current - Hold (Ih) (Max) | :250mA |
| Voltage - Reverse Standoff (Typ) | :1600V | Current - Gate Trigger (Igt) (Max) | :150mA |
| Voltage - Gate Trigger (Vgt) (Max) | :3V | Current - On State (It (RMS)) (Max) | :95A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | :1.5kA | Current - Average Rectified (Io) (per Diode) | :50A |
| Voltage - Output Difference (Typ) @ Distance | :1.6kV | ||
Mechanical
| Depth | :20mm | Width | :30mm |
| Length | :93mm | Weight | 0.12 |
| Termination | :Screw | Number of Pins | :7 |
| Package / Case | SEMIPACK1 | Material Finish | :- |
| Package Quantity | 12 | Size / Dimension | see |
| Pin Hole Diameter | :A46 | Mounting Hole Diameter | :6.4mm |
| Mounting Panel Thickness | :80mm | ||
Product Info
| Spg | 12 | Schematic | see |
| Triac Type | :Thyristor / Diode Module | Number of Units | 1 |
Environmental
| Operating Temperature | :-40°C | ||
