4802.2300
| Manufacturer | |
| Description | Conn Audio F 3 POS Solder RA Panel Mount 6 Terminal 1 Port SOCKEL 3,5MM 3P LOETANSCHLUSS SOCKET 3.5MM 3P SCREENED SDR SOCKET, 3.5MM JACK, PANEL, 3POLE SOCKET3.5MM3PSCREENEDSDR Socket; Jack 3,5 mm x 18,6 mm; female; No.of term:6; soldering |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 500 | Unit Pack | 100 |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | ||
Electrical
| Signal Lines | Stereo | Voltage Rating | 12VAC/DC |
| Current Rating (Max) | 1A | ||
Mechanical
| Depth | :18.8mm | Width | :10.7mm |
| Length | :14.2mm | Weight | 0.002 |
| Shielding | Unshielded | Termination | Solder |
| Pin Diameter | :3.5mm | Housing Color | Black |
| Mounting Type | Panel Mount | Connector Type | Phone Jack |
| Contact Finish | :Gold | Mounting Style | for panel mounting, front side nut |
| Material - Body | :Metal | Contact Material | Brass |
| Housing Material | Plastic | Package Quantity | 100 |
| Connector - Cable | socket | Color - Connectors | :Black |
| Number of Contacts | 3 | Contact Termination | :Solder |
| Color - Actuator/Cap | Silver | Pin Size - Below Flange | :3.5mm |
| Plug/Mating Plug Diameter | 3.50mm (0.141", 1/8", Mini Plug) - Headphone | Contact Material - Plating | Gold |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Spg | 100 | Type | Audio |
| Gender | F | Series | :- |
| Features | Mounting Hardware, Thread Lock | Number of Units | 1 |
| Internal Switch(s) | Three Switches | Number of Positions/Contacts | 3 Conductors, 6 Contacts |
Environmental
| Operating Temperature | -20°C ~ 70°C | ||
