RN114-0.3-02
| Manufacturer | |
| Description | Common Mode Filters / Chokes RN114-0.3/02 Common Mode Chokes Dual 47mH 10kHz 300mA 1.75Ohm DCR Thru-Hole CHOKE COMPENSATED 47MH .3A HORZ Schaffner 47mH -30 to +50% Current Compensated Choke, 300mA Idc, 1.75Ω Rdc CHOKE, COM/ASYM MODE, 2X47MH, 0.3A CURRENTCOMPENSATED0.3ASINGLEPHASECHOKE,PINCONNECTION Inductor, radial 47 mH (2x) 0.3 A (2x), RN114-0,3/02, Schaffner Schaffner RN 系列 47 mH -30 → +50% 电流补偿扼流圈, 300mA Idc, 1.75Ω Rdc |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Chokes | Lead Time | 84 Days |
| Subcategory | Common Mode Chokes | Part # Aliases | 0,3/02 0.3/02 114- RN |
| Product Category | Common Mode Filters / Chokes | Standard Package | 25 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85045020 |
| Part Status | 288-205 | Approval Agency | :UL, VDE |
| Material Flammability Rating | :UL94V-0 | ||
Electrical
| Current | 300mA | Core Type | :Common / Asymmetrical |
| Tolerance | - 30 %, + 50 % | Inductance | 47 mH |
| Filter Type | Power Line | Range deg/s | :SCHAFFNER - RN Series |
| Test Frequency | 10 kHz | Voltage - Test | :1500V |
| Voltage Rating | 250VAC | Inductance Range | :+50%, -30% |
| Current Rating - DC | :300mA | DC Resistance (DCR) | 1.75 Ohm |
| Voltage - Breakdown | 1.5kVAC | Current Rating (Max) | 0.3 A |
| DC Resistance (DCR) (Max) | :1.75ohm | Frequency - Self Resonant | DC to 1 kHz |
| Resistance - Initial (Ri) (Min) | 1750 mOhms | ||
Mechanical
| Depth | 21.8mm | Width | 21.5 mm |
| Height | 13.5mm | Length | 22.8mm |
| Weight | 0.0008 | Packaging | Tray |
| Shielding | Unshielded | Height (Max) | 0.531" (13.50mm) |
| Pitch - Post | 20.1mm | Mounting Type | Through Hole |
| Number of Pins | :4 | Package / Case | 13.2 mm |
| Length - Overall | 22.8 | Size / Dimension | 21.5 mm W x 22.5 mm L x 13.2 mm H |
| Termination Style | Through Hole | Dimensions - Overall | :22.5mm x 21.5mm x 13.2mm |
Product Info
| Type | Current Compensated Chokes | Series | RN |
| Configuration | Dual | Number of Lines | 2 |
| Industry Aliases | RN 114-0.3-02, RN 114-0.3/02, RN114-0.3/02 | For Use With/Related Products | RN114-0.3/02 |
Environmental
| Operating Temperature | - 40 C to + 125 C | ||
