CLP-104-02-F-D
| Manufacturer | |
| Description | Conn Socket Strip SKT 8 POS 1.27mm Solder ST SMD CONN RCPT 8POS DUAL .05" SMD SOCKET, 1.27MM, VERTICAL SMT, 8WAY |
| Category |
Business
| Other Names | SAM1153-04 | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85366930 |
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 1.75/Contact |
Mechanical
| Color | Black | Depth | 3.05 |
| Pitch | 1.27 mm | Height | 2.29 |
| Weight | 0.0009 | Packaging | Tube |
| Row Spacing | 0.050" (1.27mm) | Termination | Solder |
| Pitch - Post | :1.27mm | Housing Color | Black |
| Mounting Type | Surface Mount | Connector Type | Receptacle |
| Contact Finish | Gold Over Nickel | Number of Rows | 2 |
| Contact Material | Phosphor Bronze | Housing Material | Liquid Crystal Polymer |
| Length - Overall | 5.51 | Height Above Board | 0.090" (2.28mm) |
| Number of Contacts | 8 | Contact Termination | :Surface Mount Vertical |
| Number of Positions | 8 | Contact Finish Thickness | Flash |
Product Info
| Type | Socket Strip | Gender | SKT |
| Series | :CLP | Number of Positions Loaded | All |
Documents & Media
Similar Parts
FTSH-104-01-F-D
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder ST Thru-Hole CONN HEADER 8POS DUAL .05" T/H
FTS-104-03-L-D
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder ST Thru-Hole CONN HEADER 8POS DUAL .05" T/H
FTSH-104-01-L-DV
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder ST SMD Tube CONN HEADER 8POS DUAL .05" SMD HEADER, 1.27MM, 2X4WAY, SMT
FTSH-104-01-L-D-RA
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder RA Thru-Hole CONN HEADER 8POS DUAL .05" R/A HEADER, 1.27MM, 2X4WAY, R/A
FTS-104-01-L-D
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder ST Thru-Hole CONN HEADER 8POS DUAL .05" T/H HEADER, 1.27MM, VERTICAL THT, 8WAY
FTSH-104-02-FM-DV-P
samtec inc.
Conn Unshrouded Header HDR 8 POS 1.27mm Solder ST SMD Tube CONN HEADER 8POS DUAL .05" SMD
FTS-104-01-L-DV
