BH1600FVC-TR
| Manufacturer | |
| Description | Light Sensor 6-Pin WSOF T/R Ambient Light Sensors Ambient Light Sensor Analog Curr Output Ambient Light Sensor IC AMBIENT LIGHT SENSOR WSOF6 BH1600FVC-TR, Light Sensor, 6-Pin WSOF 环境光传感器, 6针 WSOF封装 PHOTODIODE Ambient Light Sensor |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 3000 | Product | Ambient Light Sensors |
| Unit Pack | 3000 | Product Category | Ambient Light Sensors |
| Standard Package | Tape & Reel | Factory Pack Quantity | 3000 |
Compliance
| RoHS | RoHS Compliant | Automotive | NO |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Sensor | No | Interface | PHOTODIODE |
| Wavelength | 560nm | Output Type | Analog |
| Range deg/s | 7 lux | Power - Rated | 260 mW |
| Rise Time (Typ) | 200 µs | Voltage - Supply | 2.4 V to 3.6 V |
| Flatness (Lambda) | 51 nm | Wavelength - Peak | 560 nm |
| LED Forward Current | 60µA | Proximity Detection | No |
| Current - Dark (Typ) | 60µA | Current - Dark (Id) (Max) | 700 µA |
Mechanical
| Width | 2.6mm | Height | 0.75mm |
| Length | 1.8mm | Footprint | SMD mm² |
| Packaging | Reel | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | 6 |
| Package / Case | 6WSOF | Package Cooled | WSOF |
| Package Quantity | WSOF | Size / Dimension | 1.8 x 2.6 x 0.75mm |
| Number of Positions | 6 | Supplier Device Package | 6-WSOF |
Product Info
| Type | Analog Current Output Ambient Light Sensors IC | RF Family/Standard | BH1600FVC |
| Output Configuration | Surface Mount | ||
Environmental
| Distance | 450 mm | Operating Temperature | + 85 C |
Documents & Media
PDF Document
